Assembly
100%

4V-3182 GUARD GP-COMPACTORS/N 87X587-606

Group No: 4V-3182
Part NumberPart NameQty
5V05371 GUARD AS1
1D4719NUT-FULL (1/2-13-THD)1
9F95222 BOLT (7/8-9X2.25-IN)6
5P82493 WASHER-HARD (24X41.5X4-MM THK)10
0T06904 BOLT (7/8-9X1.5-IN)4
0S15895 BOLT (5/8-11X1.75-IN)2
5P82476 WASHER-HARD (17X32X3.5-MM THK)4
4V98377 STRIP2
0S16218 BOLT (1/2-13X1-IN)2
5P82459 WASHER-HARD (13.5X25.5X3-MM THK)13
4V978710 GUARD1
0S159411 BOLT (3/8-16X1-IN)13
5M289412 WASHER-HARD (10.2X18.5X2.5-MM THK)29
5V046713 GUARD AS2
8S909214 BOLT (5/8-11X2.25-IN)4
5V051115 GUARD1
0S158816 BOLT (3/8-16X1.25-IN)10
5V047017 GUARD1
0S159518 BOLT (1/2-13X1.25-IN)11
1A045819 BOLT (3/4-10X1.75-IN)1
5V046620 COVER AS1
5V046421 GUARD AS1
4V449822 GUARD AS1
1D416423 HANDRAIL2
4V978824 GUARD1
4V978925 GUARD AS2
4V449726 GUARD AS1
1D416427 HANDRAIL2
0S156628 BOLT (5/8-11X1.5-IN)2
5V053629 GUARD AS1
1D4719NUT-FULL (1/2-13-THD)1
4V439430 GUARD AS1
9F2978NUT-WELD (3/8-16-THD)2
8V887131 GUARD AS1
9F2978NUT-WELD (3/8-16-THD)2
1D471732 NUT (3/8-16-THD)6
1A806333 BOLT (3/4-10X2.5-IN)4
5P824834 WASHER-HARD (20X36.5X3.5-MM THK)5
5P824735 WASHER-HARD (17X32X3.5-MM THK)4
5P7197WASHER (17X45X6-MM THK)(6.35MM)4
8V743836 PLATE1
7V606437 BOLT AS4
