System And Components
121-3053 TANK GP-FUELS/N 5FN420-UP
Group No: 121-3053
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K4370 | 1 BOLT (5/8-11X1.75-IN) | 1 | |
| 8T4122 | 2 WASHER-HARD (17X32X3.5-MM THK) | 3 | |
| 4H9027 | 3 PLUG-PIPE | 2 | |
| 1D4164 | 4 HANDRAIL | 1 | |
| 8T8917 | 5 BOLT (1/2-13X1.25-IN) | 2 | |
| 8T4223 | 6 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 1737379 | 7 TANK AS-FUEL | 1 | |
| 7X7700 | 8 CAP AS-FUEL (LOCKABLE, VENTED) | 1 | |
| 9X2205 | KIT-CAP FILTER (FUEL TANK) | 1 | |
| 9X8600 | SEAL-O-RING | 1 | |
| 6V5016 | 9 VALVE-BALL | 1 | |
| 7D8793 | 10 ELBOW-FLARED | 1 | |
| 3E7445 | 11 CLAMP-HOSE | 1 | |
| 5P0743 | 12 HOSE (30CM) | ||
| 5P7782 | 13 BOLT-LOCKING (5/8-11X3.75-IN) | 2 | |
| 4B4281 | 14 WASHER (16.8X33X2.5-MM THK) | 2 | |
| 1H8306 | 15 SCREW-PURGE (1/2-20X1.625-IN) | 1 | |
| 3B0551 | 16 PLUG-PIPE | 1 | |
| 1578858 | 17 SENDER AS-FUEL LEVEL | 1 | |
| 1693506 | KIT-DIAL SENSOR | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 6C3060 | 18 GASKET | 1 | |
| 8T4138 | 19 BOLT (M6X1X20-MM) | 6 | |
| 9X8256 | 20 WASHER (6.6X12X2-MM THK) | 6 | |
| 9P7121 | 21 STRAINER-FUEL | 1 | |
| 9U2277 | 22 CLIP AS | 1 | |
| 8T4137 | 23 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 1 |
