System And Components
163-1000 COVER GP-AIR CLEANERS/N 5YW1-237
Group No: 163-1000
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1D4164 | 1 HANDRAIL | 4 | |
| 1630999 | 2 SHELL | 1 | |
| 1644628 | 3 HINGE AS | 1 | |
| 1644629 | 4 GRILL | 1 | |
| 1644630 | 5 GRILL AS | 1 | |
| 8G0871 | HANDLE | 2 | |
| 1S4244 | 6 PIN (9.4-MM OD) | 1 | |
| 2V9166 | 7 WASHER (0.391X1X0.06-IN THK) | 2 | |
| 3B4615 | 8 PIN-COTTER | 1 | |
| 5P1076 | 9 WASHER-HARD (13.5X30X4-MM THK) | 8 | |
| 7P7975 | 10 LATCH | 1 | |
| 7X7729 | 11 WASHER (11X25X3-MM THK) | 31 | |
| 8G0873 | 12 SPRING | 1 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4133 | 14 NUT (M10X1.5-THD) | 16 | |
| 8T4136 | 15 BOLT (M10X1.5X25-MM) | 15 | |
| 8T4196 | 16 BOLT (M10X1.5X35-MM) | 10 | |
| 8T4244 | 17 NUT (M12X1.75-THD) | 8 | |
| 8T4956 | 18 BOLT (M12X1.75X35-MM) | 8 | |
| 9V0450 | 19 PIN | 1 |
