System And Components
149-3109 LATCH GP-HOODS/N 5YW1-UP
Group No: 149-3109
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1D4164 | 1 HANDRAIL | 2 | |
| 9M3835 | 2 LATCH-RUBBER | 2 | |
| 9M3837 | 3 BRACKET-CATCH | 2 | |
| 1593401 | 4 ANCHOR | 2 | |
| 2M5795 | 5 PIN-CLEVIS | 2 | |
| 3B4607 | 6 PIN-COTTER | 2 | |
| 5P1076 | 7 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 8T4121 | 8 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4133 | 9 NUT (M10X1.5-THD) | 4 | |
| 8T4136 | 10 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4205 | 11 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T4244 | 12 NUT (M12X1.75-THD) | 4 | |
| 8T4956 | 13 BOLT (M12X1.75X35-MM) | 4 | |
| 8T4138 | 14 BOLT (M6X1X20-MM) | 4 | |
| 9X8256 | 15 WASHER (6.6X12X2-MM THK) | 4 |
