194-2717 WIRING GP-ENGINES/N ASJ1-154

Group No: 194-2717
Part NumberPart NameQty
3S20931 STRAP-CABLE19
8Y80512 SPACER (10.35X16X6-MM THK)2
8Y96033 CABLE AS-STARTING MOTOR1
9U22774 CLIP AS5
11644915 BRACKET AS2
8T3490NUT-WELD (M10X1.5-THD)1
12548126 SENDER AS-TEMPERATURE (AIR INLET HEATER COOLANT)1
1028802KIT-RECEPTACLE (2-PIN)1
3E3365WEDGE-RECEPTACLE LOCK (2-PIN)1
1863735PIN-CONNECTOR (16-GA TO 18-GA)2
13098117 SENSOR GP-TEMPERATURE (ENGINE COOLANT)1
13525438 BOOT (RED)1
13807159 CABLE AS1
148829810 WIRE AS1
165780111 BRACKET AS1
6V9632NUT-WELD (M6X1-THD)1
166772112 SWITCH AS-PRESSURE (ENGINE OIL/MONITOR)1
1028802KIT-RECEPTACLE (2-PIN)2
3E3365WEDGE-RECEPTACLE LOCK (2-PIN)1
173158313 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)1
189574614 SENSOR GP-SPEED (ENGINE)1
215291015 HARNESS AS-ENGINE1
3T3044PLUG AS-CONNECTOR (25-PIN)1
7G7917PLUG-SEAL7
7G7918PLUG-SEAL7
7G7919PLUG-SEAL7
8N1521BELL AS-END1
8T8737PLUG-SEAL4
1068704SUPPRESSOR AS-ARC1
1028802KIT-RECEPTACLE (2-PIN)1
3E3365WEDGE-RECEPTACLE LOCK (2-PIN)1
1863735PIN-CONNECTOR (16-GA TO 18-GA)2
1552270KIT-CONNECTING PLUG (2-PIN)12
197471916 PLATE1
033824817 CLIP (LOOP)5
3J190718 SEAL-O-RING1
3K036019 SEAL-O-RING2
4P758120 CLIP (LADDER)9
4P813421 CLIP (LADDER)7
4S196222 CLIP (LOOP)1
5C726123 NUT (M8X1.25-THD)4
155354924 SENSOR GP-PRESSURE (DISC SAW)1
6V883725 BOLT (M6X1X16-MM)1
7C435426 CLIP1
8T412127 WASHER-HARD (11X21X2.5-MM THK)11
8T413328 NUT (M10X1.5-THD)1
8T413729 BOLT (M10X1.5X20-MM)9
8T419530 BOLT (M10X1.5X30-MM)3
8T420031 BOLT (M8X1.25X16-MM)1
8T422432 WASHER-HARD (8.8X16X2-MM THK)8
8T490833 BOLT (M8X1.25X25-MM)2
9X616534 WASHER (6.5X22X2.5-MM THK)1
202020335 PLATE AS1
189315836 SUPPRESSOR-ARC2
7C435537 CLIP1
4K886438 CLIP (LOOP)1
7J020439 SEAL-O-RING1
