System And Components
198-3890 TRIM GP-CABS/N WBE1-167
Group No: 198-3890
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2080305 | 1 LATCH AS | 1 | |
| 6C9226 | 2 FILTER ELEMENT-CAB AIR | 1 | |
| 6V8928 | 3 HOOK-COAT | 1 | |
| 9K0974 | 4 BRACKET | 1 | |
| 1088839 | 5 SUPPORT-FILTER | 1 | |
| 1356945 | 6 STOP-RUBBER | 2 | |
| 2210864 | 7 HANDLE AS | 1 | |
| 1972891 | 8 DOOR | 1 | |
| 2214513 | 9 FOAM | 1 | |
| 2210896 | 10 FOAM | 1 | |
| 1979890 | 11 ANGLE | 2 | |
| 2208421 | 12 COVER | 1 | |
| 2210898 | 13 FOAM | 1 | |
| 1979905 | 14 PLATE | 1 | |
| 2259311 | 15 PAD | 1 | |
| 2210897 | 16 FOAM | 1 | |
| 2146673 | 17 PLATE AS | 1 | |
| 2001232 | 18 PLATE | 1 | |
| 2001238 | 19 CUP | 1 | |
| 2034219 | 20 FOAM | 1 | |
| 2034220 | 21 FOAM | 1 | |
| 2034228 | 22 PLATE | 1 | |
| 2034240 | 23 PLATE | 1 | |
| 2231776 | 24 FOAM | 1 | |
| 9X8257 | 25 WASHER (17.5X30X3.5-MM THK) | 4 | |
| 8T4223 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 2128849 | 27 FLOOR MAT | 1 | |
| 2128850 | 28 FLOOR MAT | 1 | |
| 2128851 | 29 FLOOR MAT | 1 | |
| 2139205 | 30 FLOOR MAT | 1 | |
| 0950735 | 31 SCREW-MACHINE (M5X0.8X8-MM) | 2 | |
| 1H3338 | 32 LOCKWASHER | 3 | |
| 8C8585 | 33 SCREW-BUTTON HEAD (M10X1.5X20-MM) | 4 | |
| 8T4121 | 34 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4136 | 35 BOLT (M10X1.5X25-MM) | 4 | |
| 9X2040 | 36 SCREW-TRUSS HEAD (M10X1.5X25-MM) | 4 | |
| 9X2042 | 37 SCREW-TRUSS HEAD (M6X1X12-MM) | 38 | |
| 9X2044 | 38 SCREW-TRUSS HEAD (M6X1X16-MM) | 1 | |
| 8T3425 | 39 CHANNEL-TRIM (.61M) | ||
| 5P5969 | 40 SEAL (2M) | 2 | |
| 8T4191 | 41 BOLT (M10X1.5X16-MM)(74CM) | 6 | |
| 1223808 | 42 BRACKET AS | 1 | |
| 5P6872 | 43 MIRROR AS | 1 | |
| 8T4190 | 44 BOLT (M16X2X25-MM) | 4 | |
| 7X2548 | 45 BOLT (M12X1.75X16-MM) | 6 | |
| 2259310 | 46 PAD | 1 | |
| 8T9005 | 47 SEAL (88CM) |
