System And Components
243-5357 LINES GP-AIR CONDITIONERS/N WBH1-UP
Group No: 243-5357
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1059411 | 1 SUPPORT | 1 | |
| 1761902 | 2 DRYER AS-REFRIGERANT (RECEIVER) | 1 | |
| 1996286 | 3 HOSE AS | 1 | |
| 2114159 | 4 BAFFLE | 1 | |
| 2119629 | 5 BRACKET | 1 | |
| 2404762 | 6 HOSE AS | 1 | |
| 2424307 | 7 HOSE AS | 1 | |
| 2445599 | 8 HOSE AS | 1 | |
| 0672551 | 9 CLIP | 1 | |
| 1299959 | 10 CLAMP | 2 | |
| 6D1641 | 11 CLIP (LOOP) | 3 | |
| 6V7357 | 12 BOLT (M6X1X25-MM) | 2 | |
| 7F6998 | 13 LOCKWASHER | 1 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 11 | |
| 8T4133 | 15 NUT (M10X1.5-THD) | 3 | |
| 8T4136 | 16 BOLT (M10X1.5X25-MM) | 7 | |
| 8T4191 | 17 BOLT (M10X1.5X16-MM) | 1 | |
| 9M8406 | 18 CLIP (LOOP) | 3 | |
| 9X8250 | 19 CLIP (LOOP) | 3 | |
| 9X8256 | 20 WASHER (6.6X12X2-MM THK) | 2 |
