System And Components
237-0437 LINES GP-STEERING -COMMAND CONTROL STEERINGS/N M1G3242-UP
Group No: 237-0437
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4V9798 | 1 TAG-IDENTIFICATION (LETTER, NUMBER C2) | 2 | |
| 4V9799 | 2 TAG-IDENTIFICATION (LETTER, NUMBER C1) | 2 | |
| 5P1293 | 3 HOSE (13-CM) | ||
| 8C6416 | 4 FITTING (TEST) | 1 | |
| 3215283 | 5 VALVE GP-STEERING NEUTRALIZER (COMMAND CONTROL STEERING)(COMMAND CONTROL STEERING) | 2 | |
| 8J6875 | 6 VALVE GP-SHUTTLE (STEERING OIL) | 1 | |
| 8R0721 | 7 SPACER (11X16X35-MM THK) | 2 | |
| 8T4984 | 8 CLAMP-HOSE | 2 | |
| 8Y8387 | 9 BLOCK | 2 | |
| 9J3866 | 10 ADAPTER | 1 | |
| 1117775 | 11 VALVE GP-CHECK (STEERING QUAD) | 1 | |
| 1248635 | 12 VALVE GP-STEERING | 1 | |
| 1259774 | 13 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 1306692 | 14 HOSE AS | 1 | |
| 1354557 | 15 BRACKET AS | 1 | |
| 1355038 | 16 MANIFOLD | 1 | |
| 1432529 | 17 HOSE AS | 1 | |
| 3615740 | 18 SHAFT AS-STEERING | 1 | |
| 1466581 | 19 BOLT-FLAT HEAD (M12X1.75X72-MM) | 2 | |
| 1469048 | 20 HOSE AS | 1 | |
| 1471790 | 21 VALVE GP-PILOT (COMMAND CONTROL STEERING) | 1 | |
| 1504027 | 22 TEE AS | 1 | |
| 3E2310 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1542883 | 23 SCREEN GP-CASE DRAIN (STEERING PILOT) | 1 | |
| 1681968 | 24 TEE AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1266872 | TEE | 1 | |
| 1856250 | 25 FITTING AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1886364 | 26 HOSE AS | 1 | |
| 1905583 | 27 CLIP (SLOT) | 1 | |
| 1905584 | 28 CLIP (TAB) | 1 | |
| 3616038 | 29 HOSE AS | 1 | |
| 2375220 | 32 HOSE AS | 1 | |
| 2436533 | 33 HOSE AS | 1 | |
| 2436535 | 34 HOSE AS | 1 | |
| 2445623 | 35 HOSE AS | 1 | |
| 2445624 | 36 HOSE AS | 1 | |
| 2445625 | 37 TUBE AS | 1 | |
| 2451666 | 38 HOSE AS | 1 | |
| 3772087 | 39 TUBE AS | 1 | |
| 2480402 | 40 TUBE AS | 1 | |
| 2480403 | 41 TUBE AS | 1 | |
| 2480867 | 42 HOSE AS | 1 | |
| 2480869 | 43 HOSE AS | 1 | |
| 3639019 | 44 BRACKET AS | 1 | |
| 7X0752 | BOSS-WELD (M10X1.5X65-MM) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 7Y2522 | PLATE | 1 | |
| 2482587 | 45 HOSE AS | 1 | |
| 2482589 | 46 HOSE AS | 1 | |
| 2492503 | 47 HOSE AS | 1 | |
| 2492504 | 48 BRACKET AS | 1 | |
| 2492506 | 49 HOSE AS | 2 | |
| 2500787 | 50 TUBE AS | 1 | |
| 1417682 | 51 HOSE AS | 1 | |
| 2588783 | 52 HOSE AS | 1 | |
| 2943037 | 54 HOSE AS | 1 | |
| 3105325 | 55 HOSE AS | 1 | |
| 3105326 | 56 HOSE AS | 1 | |
| 1327551 | 57 SPACER (11X19X6-MM THK) | 4 | |
| 3574365 | 58 CONNECTOR AS | 4 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 3574368 | 59 CONNECTOR AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9872 | CONNECTOR | 1 | |
| 3574367 | 60 CONNECTOR AS | 2 | |
| 1J9671 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T5043 | ADAPTER | 1 | |
| 3574366 | 61 CONNECTOR AS | 5 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 3574444 | 62 ELBOW AS | 3 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 3574484 | 63 ELBOW AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 3574448 | 64 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T6684 | ELBOW | 1 | |
| 3574459 | 65 ELBOW AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 3574427 | 66 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8627 | ELBOW | 1 | |
| 3603572 | 67 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8C8988 | ELBOW | 1 | |
| 3574432 | 68 ELBOW AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488411 | 69 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 3574518 | 70 TEE AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8782 | TEE | 1 | |
| 3574539 | 71 TEE AS | 2 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 3574528 | 72 TEE AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8774 | TEE | 1 | |
| 3574540 | 73 TEE AS | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 3574494 | 74 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1645544 | 75 ELBOW AS | 1 | |
| 3E2333 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1645567 | 76 COUPLER AS-QUICK DISCONNECT (MALE) | 3 | |
| 2147568 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 3603562 | 77 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8T0078 | CONNECTOR | 1 | |
| 1645624 | 78 ELBOW AS | 1 | |
| 9X2085 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1704735 | 79 RING-RETAINING | 1 | |
| 3603549 | 80 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8T8899 | ELBOW | 1 | |
| 3603566 | 81 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8T9023 | CONNECTOR-O-RING | 1 | |
| 1915285 | 82 GROMMET | 1 | |
| 2186862 | 83 HOSE AS | 1 | |
| 2219240 | 84 HOSE AS | 3 | |
| 1B8705 | 85 KEY-WOODRUFF | 1 | |
| 1P3703 | 86 SEAL-RECTANGULAR | 1 | |
| 1P3704 | 87 SEAL-RECTANGULAR | 4 | |
| 1P4582 | 88 FLANGE-HALF | 2 | |
| 1S0994 | 90 CLIP (LOOP) | 1 | |
| 1S6420 | 91 CLIP | 2 | |
| 4D7388 | 92 CLIP | 2 | |
| 4J0520 | 93 SEAL-O-RING | 4 | |
| 4J0524 | 94 SEAL-O-RING | 2 | |
| 4J0527 | 95 SEAL-O-RING | 1 | |
| 4J5267 | 96 SEAL-O-RING | 2 | |
| 4J5477 | 97 SEAL-O-RING | 1 | |
| 1051866 | 98 CLIP | 1 | |
| 5G7020 | 99 CLIP (SLOT) | 3 | |
| 5G7021 | 100 CLIP (TAB) | 3 | |
| 5P7854 | 101 CLIP (LOOP) | 2 | |
| 5P9297 | 102 CLIP (LOOP) | 1 | |
| 6D4246 | 103 CLIP (LOOP) | 1 | |
| 6J2680 | 104 SEAL-O-RING | 1 | |
| 6V0852 | 105 CAP-DUST | 5 | |
| 7I0008 | 106 GROMMET | 1 | |
| 7I0009 | 107 CLAMP-HALF | 2 | |
| 7X2543 | 108 BOLT (M10X1.5X120-MM) | 1 | |
| 8C3205 | 109 FLANGE-HALF | 4 | |
| 8C3206 | 110 FLANGE-HALF | 2 | |
| 8C7534 | 111 CLIP | 1 | |
| 8M2773 | 112 CLIP (LOOP) | 7 | |
| 8T1889 | 113 CLIP (SLOT) | 2 | |
| 8T1890 | 114 CLIP (TAB) | 2 | |
| 8T4121 | 115 WASHER-HARD (11X21X2.5-MM THK) | 55 | |
| 8T4133 | 116 NUT (M10X1.5-THD) | 13 | |
| 8T4137 | 117 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4139 | 118 BOLT (M12X1.75X30-MM) | 6 | |
| 8T4172 | 119 BOLT (M10X1.5X80-MM) | 10 | |
| 8T4179 | 120 BOLT (M12X1.75X20-MM) | 2 | |
| 8T4182 | 121 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4184 | 122 BOLT (M12X1.75X45-MM) | 6 | |
| 8T4185 | 123 BOLT (M10X1.5X50-MM) | 4 | |
| 8T4195 | 124 BOLT (M10X1.5X30-MM) | 7 | |
| 8T4196 | 125 BOLT (M10X1.5X35-MM) | 10 | |
| 8T4198 | 126 BOLT (M10X1.5X100-MM) | 8 | |
| 8T4223 | 127 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T4244 | 128 NUT (M12X1.75-THD) | 4 | |
| 8T5005 | 129 BOLT (M10X1.5X70-MM) | 10 | |
| 8T5436 | 130 BOLT (M10X1.5X130-MM) | 2 | |
| 8Y8388 | 132 PLATE | 1 | |
| 9X2027 | 133 WASHER (11X18X2-MM THK) | 12 | |
| 9X2480 | 134 BOLT (M6X1X45-MM) | 2 | |
| 9X6582 | 135 NUT (13/16-16-THD) | 1 | |
| 9X8256 | 136 WASHER (6.6X12X2-MM THK) | 2 | |
| 2006345 | 140 SADDLE-MOUNTING (DUAL SWIVEL) | 2 | |
| 2042281 | 141 STRAP-CABLE | 5 | |
| 7X7729 | 142 WASHER (11X25X3-MM THK) | 4 | |
| 3552481 | 143 PLATE | 1 | |
| 8T4910 | 144 BOLT (M12X1.75X60-MM) | 1 | |
| 4J0519 | 145 SEAL-O-RING | 1 | |
| 1K4649 | 146 SPACER (0.516X1X1-IN THK) | 1 | |
| 3373953 | 147 GUARD-HOSE | 1 |
