System And Components
378-1666 GUARD GP-REARS/N Z4W1-UP
Group No: 378-1666
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1171647 | 1 SPRING | 1 | |
| 1930964 | 2 HANDLE AS | 1 | |
| 1930965 | 3 PIN | 1 | |
| 2076514 | 4 SPACER (17X35X35-MM THK) | 8 | |
| 2287506 | 5 BRACKET | 2 | |
| 2468370 | 6 GROMMET | 3 | |
| 2605893 | 7 HINGE AS | 2 | |
| 3781667 | 8 SUPPORT AS (RH) | 1 | |
| 3781671 | 9 SUPPORT AS (LH) | 1 | |
| 3781673 | 10 GUARD AS | 1 | |
| 3920877 | 11 ROD | 1 | |
| 1325789 | 12 CLIP (LADDER) | 5 | |
| 3B4632 | 13 PIN-COTTER | 1 | |
| 4P7581 | 14 CLIP (LADDER) | 3 | |
| 5H3193 | 15 PIN-SPRING | 2 | |
| 5P1076 | 16 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 6D4246 | 17 CLIP (LOOP) | 1 | |
| 6V8237 | 18 WASHER (26X44X4-MM THK) | 1 | |
| 7X2554 | 19 BOLT (M16X2X70-MM) | 8 | |
| 8T4121 | 20 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4136 | 21 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 22 BOLT (M10X1.5X20-MM) | 9 |
