System And Components
341-7638 PUMP GP-PISTONS/N LTE1-UP
Group No: 341-7638
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1401739 | 1 RING-RETAINING | 1 | |
| 2232321 | 2 KIT-WASHER (HYDRAULIC PUMP, MOTOR)(PISTON PUMP) | 2 | |
| 9S4191 | 3 PLUG (9/16-18-THD) | 2 | |
| 3J1907 | 4 SEAL-O-RING | 2 | |
| 2229229 | 5 RACE-BEARING | 1 | |
| 1238907 | 6 CONE-BEARING | 1 | |
| 3782829 | 7 SHAFT | 1 | |
| 8U9480 | 8 PIN | 2 | |
| 1970078 | 9 BEARING | 2 | |
| 3782812 | 10 ROTATING GP-PUMP | 1 | |
| 1314663 | 11 SHIM (6.3-MM THK) | 1 | |
| 8U2566 | 12 BEARING | 1 | |
| 3803425 | 13 KIT-SHIM (INCLUDES 8-SHIMS)(PISTON PUMP) | 1 | |
| 3782810 | 14 VALVE GP-RELIEF (PISTON PUMP) | 2 | |
| 5P5599 | SEAL-O-RING | 1 | |
| 3782815 | 15 VALVE GP-RELIEF (PISTON PUMP) | 1 | |
| 9X4619 | SEAL-O-RING | 1 | |
| 3782813 | 16 PLATE-VALVE | 1 | |
| 1012862 | 17 DOWEL | 2 | |
| 1314674 | 18 PIPE | 2 | |
| 3866605 | 19 KIT-PISTON (ACTUATOR) | 2 | |
| 6V5192 | 21 BOLT-SOCKET HEAD (M8X1.25X30-MM) | 4 | |
| 3782816 | 22 LEVER-CONTROL | 1 | |
| 3782817 | 23 VALVE GP-PUMP CONTROL | 1 | |
| 3E6910 | 24 BOLT-SOCKET HEAD (M12X1.75X70-MM) | 3 | |
| 8C3413 | 25 BOLT-SOCKET HEAD (M12X1.75X120-MM) | 4 | |
| 7X1553 | 26 SEAL-LIP TYPE | 1 | |
| 1238909 | 27 CONE-BEARING | 1 | |
| 2248200 | KIT-SEAL (PISTON PUMP) | 1 |
