System And Components
437-4723 BOX GP-STORAGES/N JEY1-UP
Group No: 437-4723
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P0540 | 1 NUT-HEX FULL (9/16-18-THD) | 2 | |
| 2462641 | 2 PADLOCK GP | 1 | |
| 5P8500 | KEY | 1 | |
| 8T1578 | 3 PAWL (LATCH) | 1 | |
| 8Y4000 | 4 LATCH AS (T-BAR, COMPARTMENT) | 1 | |
| 4373103 | 5 ROD AS | 1 | |
| 4914774 | 6 BOX AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 9 | |
| 2375586 | SEAL (494-CM) | ||
| 3335219 | SEAL (125-CM) | ||
| 4914775 | 7 DOOR AS | 1 | |
| 4925174 | 8 BAR AS | 1 | |
| 1313957 | BAR | 1 | |
| 1358575 | 9 BOLT AS | 4 | |
| 3B4615 | 10 PIN-COTTER | 3 | |
| 5P8522 | 11 GROMMET | 1 | |
| 6V7744 | 12 LOCKNUT (M10X1.5-THD) | 2 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4136 | 14 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4138 | 15 BOLT (M6X1X20-MM) | 2 | |
| 8T4191 | 16 BOLT (M10X1.5X16-MM) | 1 | |
| 9X8256 | 17 WASHER (6.6X12X2-MM THK) | 2 |
