System And Components
164-8174 LINES GP-STEERINGS/N 2KR3722-4552
Group No: 164-8174
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P6412 | 1 HOSE (12CM) | ||
| 3E2310 | 2 TEE | 4 | |
| 3H5808 | 3 SPRING | 1 | |
| 5P2094 | 4 HOSE | 10 | |
| 5P2230 | 5 CLAMP-HOSE | 4 | |
| 6V0484 | 6 ELBOW | 1 | |
| 6V0852 | 7 CAP-DUST | 8 | |
| 6V3965 | 8 FITTING (QUICK DISCONNECT) | 8 | |
| 8J1553 | 9 VALVE GP-STEERING NEUTRALIZER | 2 | |
| 8J6875 | 10 VALVE GP-SHUTTLE | 1 | |
| 2M9780 | SEAL-O-RING | 2 | |
| 4B9784 | BALL | 1 | |
| 4T9905 | ADAPTER | 2 | |
| 8T0130 | 11 ELBOW | 1 | |
| 8T4984 | 12 CLAMP-HOSE | 2 | |
| 8T9107 | 13 TEE | 2 | |
| 8Y8388 | 14 PLATE | 2 | |
| 5P1262 | 15 HOSE (16CM) | ||
| 9J3866 | 16 ADAPTER | 1 | |
| 9U8347 | 17 HOSE AS | 1 | |
| 1007530 | 18 HOSE AS | 1 | |
| 1116923 | 19 HOSE AS | 1 | |
| 1117775 | 20 VALVE GP-CHECK (STEERING QUAD) | 1 | |
| 1146046 | 21 TUBE AS | 1 | |
| 1146049 | 22 TUBE AS | 1 | |
| 1146051 | 23 ELBOW | 1 | |
| 1146053 | 24 TUBE AS | 1 | |
| 1146064 | 25 BLOCK-MANIFOLD | 1 | |
| 1169563 | 26 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1169575 | 27 HOSE AS | 1 | |
| 1169576 | 28 HOSE AS | 1 | |
| 1169577 | 29 HOSE AS | 1 | |
| 1169578 | 30 HOSE AS | 1 | |
| 1169579 | 31 HOSE AS | 1 | |
| 1250151 | 32 BLOCK | 4 | |
| 1250154 | 33 HOSE AS | 1 | |
| 1259774 | 34 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 1266872 | 35 TEE | 1 | |
| 1279323 | 36 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1280486 | 37 HOSE AS | 1 | |
| 1338789 | 38 HOSE AS | 1 | |
| 1465776 | 39 SHAFT AS-STEERING | 1 | |
| 1466581 | 40 BOLT-FLAT HEAD (M12X1.75X72-MM) | 2 | |
| 1490272 | 41 MANIFOLD | 1 | |
| 1508985 | 42 HOSE AS | 1 | |
| 1542883 | 43 SCREEN GP-CASE DRAIN (STEERING PILOT) | 1 | |
| 1591583 | 44 HOSE AS | 1 | |
| 1648175 | 45 ANGLE AS | 1 | |
| 1648177 | 46 HOSE AS | 1 | |
| 1648178 | 47 HOSE AS | 1 | |
| 1648180 | 48 HOSE AS | 1 | |
| 1648181 | 49 HOSE AS | 1 | |
| 1648183 | 50 TUBE AS | 1 | |
| 1648184 | 51 HOSE AS | 1 | |
| 1660362 | 52 HOSE AS | 1 | |
| 1668495 | 53 VALVE GP-STEERING | 1 | |
| 1689198 | 54 HOSE AS | 1 | |
| 1689202 | 55 HOSE AS | 1 | |
| 1689204 | 56 HOSE AS | 1 | |
| 1689205 | 57 HOSE AS | 1 | |
| 1689206 | 58 HOSE AS | 1 | |
| 1689207 | 59 BRACKET AS | 1 | |
| 1693695 | 60 BRACKET AS | 1 | |
| 1694961 | 61 HOSE AS | 1 | |
| 1714763 | 62 ANGLE | 1 | |
| 1714764 | 63 HOSE AS | 1 | |
| 1346706 | 64 HOSE AS | 1 | |
| 1730439 | 65 VALVE GP-PILOT (STEERING) | 1 | |
| 1146052 | 66 TUBE AS | 1 | |
| 1144238 | 67 PLATE AS | 1 | |
| 1146048 | 68 TUBE AS | 1 | |
| 1B8705 | 69 KEY-WOODRUFF | 1 | |
| 1J9671 | 70 SEAL-O-RING | 2 | |
| 1P3703 | 71 SEAL-RECTANGULAR | 2 | |
| 1P3705 | 72 SEAL-RECTANGULAR | 1 | |
| 1S0994 | 73 CLIP (LOOP) | 7 | |
| 2M9780 | 74 SEAL-O-RING | 1 | |
| 3D2824 | 75 SEAL-O-RING | 3 | |
| 3J1907 | 76 SEAL-O-RING | 30 | |
| 3J7354 | 77 SEAL-O-RING | 1 | |
| 3K0360 | 78 SEAL-O-RING | 8 | |
| 4D7733 | 79 CLIP (LOOP) | 2 | |
| 4J0520 | 80 SEAL-O-RING | 8 | |
| 4J5267 | 81 SEAL-O-RING | 6 | |
| 5H8848 | 82 SEAL-O-RING | 2 | |
| 8T4195 | 83 BOLT (M10X1.5X30-MM) | 8 | |
| 5P4325 | 84 CLIP (LOOP) | 1 | |
| 6D4247 | 85 CLIP | 1 | |
| 6V8397 | 86 SEAL-O-RING | 39 | |
| 6V8398 | 87 SEAL-O-RING | 11 | |
| 6V8400 | 88 SEAL-O-RING | 1 | |
| 6V8634 | 90 CONNECTOR | 4 | |
| 6V8636 | 91 CONNECTOR | 6 | |
| 6V8637 | 92 CONNECTOR | 2 | |
| 6V8639 | 93 CONNECTOR | 1 | |
| 6V8723 | 94 ELBOW | 1 | |
| 6V8724 | 95 ELBOW | 4 | |
| 6V8774 | 96 TEE | 1 | |
| 6V8782 | 97 TEE | 1 | |
| 6V9001 | 99 ELBOW | 2 | |
| 6V8638 | 100 CONNECTOR | 1 | |
| 6V9168 | 102 NUT (11/16-16-THD) | 1 | |
| 6V9200 | 103 ELBOW | 1 | |
| 6V9746 | 104 SEAL-O-RING | 2 | |
| 6V9836 | 105 TEE-SWIVEL | 1 | |
| 1S1015 | 106 CLIP (LOOP) | 1 | |
| 6V9850 | 107 ELBOW | 3 | |
| 6V9851 | 108 ELBOW | 2 | |
| 7M8485 | 111 SEAL-O-RING | 1 | |
| 7X2543 | 112 BOLT (M10X1.5X120-MM) | 1 | |
| 8C3205 | 113 FLANGE-HALF | 12 | |
| 8C3206 | 114 FLANGE-HALF | 6 | |
| 8C3364 | 115 ELBOW | 1 | |
| 8C8988 | 116 ELBOW | 1 | |
| 8C8989 | 117 ELBOW | 1 | |
| 8M2773 | 118 CLIP (LOOP) | 2 | |
| 8T1905 | 119 ELBOW | 1 | |
| 8T4121 | 120 WASHER-HARD (11X21X2.5-MM THK) | 81 | |
| 8T4133 | 121 NUT (M10X1.5-THD) | 3 | |
| 8T4136 | 122 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4137 | 123 BOLT (M10X1.5X20-MM) | 10 | |
| 8T4139 | 124 BOLT (M12X1.75X30-MM) | 3 | |
| 8T4172 | 125 BOLT (M10X1.5X80-MM) | 4 | |
| 8T4182 | 126 BOLT (M10X1.5X45-MM) | 6 | |
| 8T4183 | 127 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4185 | 128 BOLT (M10X1.5X50-MM) | 2 | |
| 8T4192 | 129 BOLT (M12X1.75X25-MM) | 4 | |
| 8T4196 | 130 BOLT (M10X1.5X35-MM) | 31 | |
| 8T4223 | 131 WASHER-HARD (13.5X25.5X3-MM THK) | 23 | |
| 8T4244 | 132 NUT (M12X1.75-THD) | 2 | |
| 8T5005 | 133 BOLT (M10X1.5X70-MM) | 12 | |
| 8T5043 | 134 ADAPTER | 2 | |
| 8T5436 | 135 BOLT (M10X1.5X130-MM) | 2 | |
| 8T6466 | 136 BOLT (M10X1.5X60-MM) | 8 | |
| 8T6696 | 137 TEE-O-RING | 1 | |
| 8T6868 | 138 BOLT (M12X1.75X80-MM) | 4 | |
| 8T8919 | 139 BOLT (1/2-13X1.75-IN) | 2 | |
| 9D1829 | 140 CLIP | 1 | |
| 9S8008 | 141 PLUG (1-1/16-12-THD) | 1 | |
| 9X2027 | 142 WASHER (11X18X2-MM THK) | 6 | |
| 9X2480 | 143 BOLT (M6X1X45-MM) | 2 | |
| 9X8256 | 145 WASHER (6.6X12X2-MM THK) | 2 |
