257-6176 CONTROL GP-STEERINGS/N LCS1-UP

Group No: 257-6176 · Commonality

Part Number	Part Name	Qty
5P9209	1 BEARING AS-NEEDLE	4
1143349	2 SCREW-PAN HEAD (M5X0.8X30-MM)	4
1236190	3 SPACER (10.2X16X16-MM THK)	4
1268165	4 PLATE	2
1268166	5 PLATE	2
1345245	6 BOLT (M10X1.5X30-MM)	4
1589955	7 PLATE	2
1650050	8 SHAFT	2
1655010	9 SPRING	4
2067893	10 BOLT (M6X1X12-MM)	2
2576177	11 FLOORPLATE AS	1
1582229	SUPPORT AS-STEERING COLUMN	2
1582231	SUPPORT AS-BRAKE	1
2625630	12 PLATE AS	2
2625634	13 SHAFT AS	2
2661467	14 SENSOR GP-POSITION (ROTARY)(STEERING CONTROL)	2
2790127	15 PLATE	1
2943183	16 PLATE AS	1
2943184	17 PLATE AS	1
2943185	18 PLATE	1
2943186	19 PEDAL AS	2
5C9553	20 BOLT (M6X1X16-MM)	6
5P4115	21 WASHER-HARD (7.2X19X2-MM THK)	8
6V0894	22 SEAL-O-RING	2
7X7729	23 WASHER (11X25X3-MM THK)	4
8T0328	24 WASHER-HARD (5.5X10X1-MM THK)	4
8T4121	25 WASHER-HARD (11X21X2.5-MM THK)	10
8T4133	26 NUT (M10X1.5-THD)	2
8T4136	27 BOLT (M10X1.5X25-MM)	4
8T4137	28 BOLT (M10X1.5X20-MM)	10
9X2042	29 SCREW-TRUSS HEAD (M6X1X12-MM)	12
