System And Components
485-1309 ROTATOR GP-HYDRAULICPART OF 490-6895 GRAPPLE GP-HYDRAULIC
Group No: 485-1309
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5W2817 | 1 FITTING-GREASE | 5 | |
| 0931434 | 2 SEAL-LIP TYPE | 2 | |
| 2768665 | 3 GEAR & BEARING GP | 1 | |
| 2301621 | SEAL (170-CM) | ||
| 3696861 | 4 PLUG AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 3603682 | PLUG-O-RING | 1 | |
| 3696863 | 5 PLUG AS | 2 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 3603685 | PLUG | 1 | |
| 3721540 | 6 HEAD | 1 | |
| 4709239 | 7 MOTOR & MANIFOLD GP-ROTATOR | 1 | |
| 4851303 | 8 SWIVEL GP | 1 | |
| 4851307 | 9 HOUSING AS-ROTATOR | 1 | |
| 1946246 | INSERT | 1 | |
| 4906907 | 10 BOSS | 2 | |
| 1179432 | 11 BUSHING | 2 | |
| 1488327 | 12 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1591119 | 13 LOCKWASHER | 12 | |
| 2666712 | 14 BOLT-SOCKET HEAD (M20X2.5X160-MM) | 16 | |
| 3E6780 | 15 SEAL-O-RING | 2 | |
| 3E6786 | 16 SEAL-O-RING | 3 | |
| 6V9832 | 17 CAP (ORFS) | 2 | |
| 8C8729 | 18 BOLT-SOCKET HEAD (M12X1.75X80-MM) | 4 | |
| 8T4648 | 19 BOLT (M12X1.75X70-MM) | 8 |
