229-2273 WIRING GP-POWER GUARDS/N CRD1-UP

Group No: 229-2273 · Commonality
Part NumberPart NameQty
5M66681 SCREW-MACHINE (8-32X0.75-IN)2
7K11812 STRAP-CABLE21
15547913 BRACKET AS1
15713564 SWITCH AS-TOGGLE (MIDDLE BOTTOM GUARD ACTUATOR)1
3E3389WEDGE-RECEPTACLE LOCK (8-PIN)1
6T3631NUT-HEX (15/32-32-THD)2
6T3632LOCKWASHER1
6T3633RING-LOCKING1
9G3695PLUG-SEAL2
1028806KIT-RECEPTACLE (8-PIN)1
15713645 SWITCH AS-TOGGLE (REAR BOTTOM GUARD ACTUATOR)1
3E3383WEDGE-RECEPTACLE LOCK (6-PIN)1
6T3631NUT-HEX (15/32-32-THD)2
6T3632LOCKWASHER1
6T3633RING-LOCKING1
1028805KIT-RECEPTACLE (6-PIN)1
22922746 WIRE AS1
22922767 HARNESS AS-CHASSIS (POWER GUARD)1
1552265KIT-CONNECTING PLUG (8-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)2
1552274KIT-CONNECTING PLUG (6-PIN)1
13053008 CLIP1
4B42749 WASHER (5.5X13X1.2-MM THK)2
4B204310 NUT (8-32-THD)2
8T412111 WASHER-HARD (11X21X2.5-MM THK)1
8T413712 BOLT (M10X1.5X20-MM)1
9H195813 CIRCUIT BREAKER GP (20-AMPERE)1
6V8376SCREW-MACHINE (8-32X0.25-IN)2
9B7233LOCKWASHER2
