System And Components
180-1634 AIR COMPRESSOR GPS/N 3HS1-UP; 4KW1-UP; 7TZ1-UP
Group No: 180-1634
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1802514 | 1 COMPRESSOR | 1 | |
| 1806045 | 2 FITTING-STRAIGHT | 1 | |
| 1479054 | 3 SEAL-O-RING | 1 | |
| 1809554 | 4 REDUCER | 1 | |
| 1480391 | 5 SEAL-O-RING | 1 | |
| 1809551 | 6 FITTING | 1 | |
| 1809553 | 7 FITTING-STRAIGHT | 1 | |
| 1547608 | 8 NUT-COMPRESSION | 1 | |
| 1549069 | 9 FITTING-COMPRESSION | 1 | |
| 1809555 | 10 BOLT | 3 | |
| 8T4957 | 11 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 1 | |
| 1519077 | 12 WASHER | 4 | |
| 1801677 | 13 BRACKET | 1 | |
| 1801678 | 14 ANGLE | 1 | |
| 1801676 | 15 BRACKET | 1 | |
| 1809552 | 16 FITTING-STRAIGHT | 1 | |
| 1519028 | 17 BOLT | 2 | |
| 1809556 | 18 BOLT | 2 | |
| 1519076 | 19 WASHER | 4 |
