Assembly
100%

160-2673 BOOM & STICK GPS/N 4XR198-UP

Group No: 160-2673
Part NumberPart NameQty
15595471 NUT1
15600932 NUT4
15777953 LINK1
15778424 LINK AS1
1577740PLATE2
1577795LINK1
15956055 LINK & BEARING AS1
1577822BOSS2
1640138BUSHING4
1640139BUSHING8
16152706 WASHER1
16152727 PIN1
16152738 PIN4
16152789 PIN1
161528010 WASHER4
161538011 FITTING1
161531512 SCREW2
3H012213 FITTING-GREASE (1/8-27)10
161555814 NUT1
163400215 STICK GP1
8T4121WASHER-HARD (11X21X2.5MM THK)14
8T4185BOLT (M10X1.5X50MM)10
8T4195BOLT (M10X1.5X30MM)4
1577750PLATE AS1
1577754PLATE AS2
1577740PLATE2
163400316 EXTENSION GP-STICK1
8T4121WASHER-HARD (11X21X2.5MM THK)2
8T4137BOLT (M10X1.5X20MM)2
0960001BOLT-SOCKET HEAD (M8X1.25X40MM)4
1595563ROD1
1595565ROD1
1595566PLATE1
163404217 GUARD AS1
164009418 WASHER1
172348319 BOOM GP1
8T422320 WASHER-HARD (13.5X25.5X3MM THK)2
8T417921 BOLT (M12X1.75X20MM)2
166246322 PLATE (10MM)NULL
166246523 PLATE (11MM)NULL
161529424 PLATE (12MM)NULL
166246725 PLATE (13MM)NULL
166246926 PLATE (14MM)NULL
165242727 SHIMNULL
