Assembly
100%

291-8849 LINES GP-CONNECTING -HITCHS/N L4E2834-UP

Group No: 291-8849
Part NumberPart NameQty
16060131 HOSE AS1
19469332 HOSE AS1
19477113 HOSE AS2
20456964 HOSE AS1
33628175 HARNESS AS-HITCH1
7X2470ADAPTER2
3437066HOSE AS1
2V2043NUT-BULKHEAD (1-5/8-12-THD)2
1809214NUT (1-11/16-18-THD)1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)8
9W0852PIN-CONNECTOR (14-GA TO 16-GA)6
9X3401PIN-CONNECTOR (16-GA TO 18-GA)14
1261767PIN-CONNECTOR (14-GA TO 16-GA)14
2722838PLUG AS-CONNECTOR (31-PIN)1
8T8737PLUG-SEAL6
2722840RECEPTACLE AS-CONNECTOR (31-PIN)1
8T8730SOCKET-CONNECTOR (16-GA TO 20-GA)8
9W0844SOCKET-CONNECTOR (14-GA TO 16-GA)6
1945226TERMINAL AS (16-GA)14
1945227TERMINAL AS (14-GA)14
34370656 HOSE AS1
43423977 HOSE AS1
1P45798 FLANGE-HALF4
1P45829 FLANGE-HALF4
4J052010 SEAL-O-RING4
4J052411 SEAL-O-RING2
4J052712 SEAL-O-RING2
7X254313 BOLT (M10X1.5X120-MM)4
7X254914 BOLT (M12X1.75X100-MM)4
7X255015 BOLT (M12X1.75X110-MM)4
8C320616 FLANGE-HALF4
8T412117 WASHER-HARD (11X21X2.5-MM THK)8
8T418418 BOLT (M12X1.75X45-MM)8
8T419619 BOLT (M10X1.5X35-MM)4
8T422320 WASHER-HARD (13.5X25.5X3-MM THK)20
8T424421 NUT (M12X1.75-THD)4
