System And Components
507-7019 HOUSING GP-AXLES/N 9SD523-UP
Group No: 507-7019
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2K0715 | 1 WASHER-THRUST (5.03X6.71X0.250-IN THK) | 2 | |
| 4V5099 | 2 COVER | 1 | |
| 5H3701 | 3 SCREW-PURGE | 4 | |
| 1094731 | 4 PLATE | 1 | |
| 1869135 | 5 SUPPORT | 1 | |
| 1869175 | 6 STUD (M16X2X244-MM) | 4 | |
| 1869176 | 7 STUD (M16X2X173-MM) | 4 | |
| 1869182 | 8 TRUNNION | 1 | |
| 4868972 | 9 SUPPORT | 1 | |
| 2131368 | 10 BUSHING | 1 | |
| 2131370 | 11 BUSHING | 1 | |
| 2263292 | 12 GUARD AS | 1 | |
| 5077014 | 13 PLATE AS | 1 | |
| 5077015 | 14 PLATE AS | 1 | |
| 5077023 | 15 HOUSING-AXLE (RH) | 1 | |
| 5077024 | 16 HOUSING-AXLE (LH) | 1 | |
| 5092221 | 17 RETAINER AS | 1 | |
| 3570339 | DOWEL | 3 | |
| 5092222 | 18 RETAINER AS | 1 | |
| 3570339 | DOWEL | 3 | |
| 0950673 | 19 BOLT-SOCKET HEAD (M12X1.75X60-MM) | 4 | |
| 1383252 | 20 BOLT-12 POINT HEAD | 3 | |
| 1497727 | 21 NUT (M16X2-THD) | 8 | |
| 1703394 | 22 BOLT-12 POINT HEAD | 18 | |
| 1703396 | 23 BOLT-12 POINT HEAD | 3 | |
| 2222462 | 24 BOLT-12 POINT HEAD | 18 | |
| 2264192 | 25 WASHER-HARD (21.5X35X8-MM THK) | 42 | |
| 3K0360 | 26 SEAL-O-RING | 4 | |
| 4K7239 | 27 DOWEL | 2 | |
| 5H3252 | 28 SEAL-O-RING | 2 | |
| 5P1076 | 29 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 5P7456 | 30 SEAL-LIP TYPE | 2 | |
| 6K2430 | 31 SEAL-LIP TYPE | 1 | |
| 6V3531 | 32 BOLT (M20X2.5X50-MM) | 4 | |
| 1783707 | 33 BOLT (M16X2X50-MM) | 12 | |
| 7M8485 | 34 SEAL-O-RING | 2 | |
| 7X0599 | 35 WASHER-HARD (13X20X2-MM THK) | 4 | |
| 7X2623 | 36 RING-RETAINING | 1 | |
| 8T3282 | 37 WASHER-HARD (22X35X3.5-MM THK) | 4 | |
| 8T4139 | 38 BOLT (M12X1.75X30-MM) | 6 | |
| 8T8883 | 39 SEAL-O-RING | 2 | |
| 9S8005 | 40 PLUG (3/4-16-THD) | 4 | |
| 9S9334 | 41 PLUG (1-5/16-12-THD) | 2 | |
| 9X8268 | 42 WASHER (17.5X30X3.5-MM THK) | 18 | |
| 1A1135 | 43 BOLT (5/8-11X2-IN) | 6 |
