System And Components
296-4371 LINES GP-FUELLH TIER II
Group No: 296-4371
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0436 | 1 GASKET (FUEL PRIMING PUMP) | 1 | |
| 2T1397 | 2 CLAMP | 2 | |
| 3S2093 | 3 STRAP-CABLE | 2 | |
| 3W6181 | 4 BRACKET | 1 | |
| 5K8652 | 5 BRACKET | 2 | |
| 1250971 | 7 HOSE AS | 1 | |
| 1375541 | 8 PUMP GP-FUEL PRIMING | 1 | |
| 1963617 | 9 HOSE AS | 1 | |
| 2037947 | 10 HOSE AS | 1 | |
| 2218209 | 11 HOSE AS | 1 | |
| 2236345 | 12 MANIFOLD-FUEL | 1 | |
| 2336742 | 13 VALVE GP-CHECK (FUEL) | 1 | |
| 2413286 | 14 HARNESS AS-SENSOR | 1 | |
| 2591386 | 15 SUPPORT AS | 1 | |
| 8T5912 | NUT-WELD (3/8-16-THD) | 4 | |
| 2914339 | 16 TUBE AS | 1 | |
| 2928125 | 17 TUBE AS | 1 | |
| 2933053 | 18 TUBE AS | 1 | |
| 2933054 | 19 TUBE AS | 1 | |
| 2964374 | 20 TUBE AS | 1 | |
| 3077683 | 21 HOSE AS | 1 | |
| 3085344 | 22 BRACKET | 1 | |
| 3135683 | 23 TUBE AS | 1 | |
| 1184728 | 24 ELBOW | 1 | |
| 0336042 | 25 SEAL-O-RING | 10 | |
| 0L1351 | 26 BOLT (3/8-16X0.875-IN) | 1 | |
| 0S1590 | 27 BOLT (3/8-16X2-IN) | 2 | |
| 0S1591 | 28 BOLT (3/8-16X1.5-IN) | 1 | |
| 0S1594 | 29 BOLT (3/8-16X1-IN) | 4 | |
| 0T0065 | 30 BOLT (3/8-16X3.5-IN) | 2 | |
| 1013121 | 31 SPACER (10.5X25X25-MM THK) | 4 | |
| 1266872 | 32 TEE | 1 | |
| 1860357 | 33 CLIP | 2 | |
| 1860359 | 34 CLIP | 1 | |
| 1A2029 | 35 BOLT (3/8-16X1.125-IN) | 1 | |
| 1B7182 | 36 BOLT (5/16-18X1.25-IN) | 1 | |
| 1V1984 | 37 CLIP | 1 | |
| 3065494 | 38 CLIP (LOOP) | 2 | |
| 3J1907 | 39 SEAL-O-RING | 2 | |
| 3K0360 | 40 SEAL-O-RING | 1 | |
| 4D7794 | 41 CLIP | 3 | |
| 4H4033 | 42 BOLT (5/8-18X1.375-IN) | 1 | |
| 5P8167 | 43 BOLT (3/8-16X0.625-IN) | 1 | |
| 5M2894 | 44 WASHER-HARD (10.2X18.5X2.5-MM THK) | 17 | |
| 5P0537 | 45 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 5P4115 | 46 WASHER-HARD (7.2X19X2-MM THK) | 2 | |
| 5P8247 | 47 WASHER-HARD (17X32X3.5-MM THK) | 3 | |
| 6F7316 | 48 BOLT (5/8-18X1-IN) | 2 | |
| 6V5048 | 49 SEAL-O-RING | 2 | |
| 6V8397 | 50 SEAL-O-RING | 23 | |
| 6V8636 | 51 CONNECTOR | 1 | |
| 6V8724 | 52 ELBOW | 5 | |
| 6V8730 | 53 UNION (FACE SEAL) | 3 | |
| 6V8781 | 54 TEE | 1 | |
| 6V9807 | 55 UNION | 3 | |
| 6V9829 | 56 CAP (ORFS) | 1 | |
| 7B2742 | 57 BOLT (1/4-20X1.25-IN) | 2 | |
| 7W7381 | 58 FITTING-OUTLET | 1 | |
| 8C6869 | 59 CONNECTOR | 1 | |
| 8L2786 | 60 SEAL-O-RING | 1 | |
| 9M1974 | 61 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9S4182 | 62 PLUG (7/16-20-THD) | 1 | |
| 9S4191 | 63 PLUG (9/16-18-THD) | 1 | |
| 9S8002 | 64 PLUG (7/16-20-THD) | 1 | |
| 9S8004 | 65 PLUG (9/16-18-THD) | 1 | |
| 9S8005 | 66 PLUG (3/4-16-THD) | 1 | |
| 9S8750 | 67 NUT-FULL (1/4-20-THD) | 1 | |
| 9S8752 | 68 NUT-FULL (3/8-16-THD) | 5 | |
| 3E2332 | 69 ELBOW | 1 | |
| 3G4005 | 70 LINK | 1 | |
| 9X2297 | 71 CONNECTOR | 1 |
