System And Components
323-6480 LINES GP-FUELDUPLEX, LH
Group No: 323-6480
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0436 | 1 GASKET (FUEL PRIMING PUMP) | 1 | |
| 2T1397 | 2 CLAMP | 2 | |
| 3S2093 | 3 STRAP-CABLE | 2 | |
| 3W6181 | 4 BRACKET | 1 | |
| 5K8652 | 5 BRACKET | 2 | |
| 1375541 | 6 PUMP GP-FUEL PRIMING | 1 | |
| 1963617 | 7 HOSE AS | 1 | |
| 2037947 | 8 HOSE AS | 1 | |
| 2218209 | 9 HOSE AS | 1 | |
| 2236345 | 10 MANIFOLD-FUEL | 1 | |
| 2336742 | 11 VALVE GP-CHECK (FUEL) | 1 | |
| 2392340 | 12 FILTER GP-FUEL | 1 | |
| 2413286 | 13 HARNESS AS-SENSOR | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 6I4347 | BOOT (4-PIN) | 2 | |
| 2591386 | 14 SUPPORT AS | 1 | |
| 8T5912 | NUT-WELD (3/8-16-THD) | 4 | |
| 2914339 | 15 TUBE AS | 1 | |
| 2928125 | 16 TUBE AS | 1 | |
| 2933053 | 17 TUBE AS | 1 | |
| 2933054 | 18 TUBE AS | 1 | |
| 2964374 | 19 TUBE AS | 1 | |
| 3077683 | 20 HOSE AS | 1 | |
| 3085344 | 21 BRACKET | 1 | |
| 3135683 | 22 TUBE AS | 1 | |
| 0335853 | 23 SEAL-O-RING | 2 | |
| 0336042 | 24 SEAL-O-RING | 12 | |
| 5S7379 | 25 BOLT (3/8-16X0.875-IN) | 4 | |
| 0S1590 | 26 BOLT (3/8-16X2-IN) | 2 | |
| 4L9337 | 27 BOLT (3/8-16X1.5-IN) | 1 | |
| 0S1594 | 28 BOLT (3/8-16X1-IN) | 2 | |
| 0T0065 | 29 BOLT (3/8-16X3.5-IN) | 2 | |
| 1013121 | 30 SPACER (10.5X25X25-MM THK) | 4 | |
| 2004262 | 31 HOSE AS | 1 | |
| 1266872 | 32 TEE | 1 | |
| 1860357 | 33 CLIP | 2 | |
| 1860359 | 34 CLIP | 1 | |
| 8T2502 | 35 BOLT (3/8-16X1.125-IN) | 1 | |
| 1B7182 | 36 BOLT (5/16-18X1.25-IN) | 1 | |
| 1V1984 | 37 CLIP | 1 | |
| 3065494 | 38 CLIP (LOOP) | 2 | |
| 3K0360 | 39 SEAL-O-RING | 1 | |
| 4D7794 | 40 CLIP | 3 | |
| 4H4033 | 41 BOLT (5/8-18X1.375-IN) | 1 | |
| 5M2894 | 42 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 5P0537 | 43 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 5P4115 | 44 WASHER-HARD (7.2X19X2-MM THK) | 2 | |
| 5P8167 | 45 BOLT (3/8-16X0.625-IN) | 1 | |
| 5P8247 | 46 WASHER-HARD (17X32X3.5-MM THK) | 3 | |
| 6F7316 | 47 BOLT (5/8-18X1-IN) | 2 | |
| 6V8397 | 48 SEAL-O-RING | 22 | |
| 6V8636 | 49 CONNECTOR | 1 | |
| 6V8724 | 50 ELBOW | 4 | |
| 6V8730 | 51 UNION (FACE SEAL) | 2 | |
| 6V8781 | 52 TEE | 1 | |
| 6V9807 | 53 UNION | 4 | |
| 7B2742 | 55 BOLT (1/4-20X1.25-IN) | 1 | |
| 7W7381 | 56 FITTING-OUTLET | 1 | |
| 8C6869 | 57 CONNECTOR | 1 | |
| 9M1974 | 58 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9S4182 | 59 PLUG (7/16-20-THD) | 1 | |
| 9S4191 | 60 PLUG (9/16-18-THD) | 1 | |
| 9S8002 | 61 PLUG (7/16-20-THD) | 1 | |
| 9S8004 | 62 PLUG (9/16-18-THD) | 1 | |
| 9S8005 | 63 PLUG (3/4-16-THD) | 1 | |
| 6V8185 | 64 NUT (1/4-20-THD) | 1 | |
| 6V8801 | 65 NUT (3/8-16-THD) | 5 | |
| 9X2297 | 66 CONNECTOR | 1 | |
| 3E2332 | 69 ELBOW | 1 | |
| 3G4005 | 70 LINK | 1 | |
| 8T4896 | 71 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 7X2501 | 72 BOLT (1/4-20X1.25-IN) | 1 |
