System And Components
111-2012 MOTOR GP-TRAVELS/N 8AL1902-2556
Group No: 111-2012
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T9599 | 1 RING-RETAINING | 1 | |
| 9T4912 | 2 SEAL-LIP TYPE | 1 | |
| 1481862 | 3 HOUSING | 1 | |
| 1219910 | 7 RING | 1 | |
| 1219911 | 8 BEARING | 1 | |
| 1219912 | 9 SHAFT | 1 | |
| 8U9480 | 10 PIN | 2 | |
| 1219913 | 11 BEARING | 2 | |
| 1907684 | 12 SWASHPLATE | 1 | |
| 1219915 | 13 SLEEVE | 3 | |
| 1219916 | 14 PISTON | 9 | |
| 1219917 | 15 WASHER (66.5X133X5.5-MM THK) | 1 | |
| 1219918 | 16 PLATE | 1 | |
| 1219919 | 17 PLATE | 1 | |
| 1219920 | 18 PLATE | 1 | |
| 1219921 | 19 PLATE | 1 | |
| 8U3297 | 20 BOLT (M10X1.5X25-MM) | 4 | |
| 1219922 | 21 PLATE | 1 | |
| 1219923 | 22 PLATE | 1 | |
| 1219924 | 23 PLATE | 1 | |
| 1219925 | 24 PLATE | 1 | |
| 1219926 | 25 HOUSING | 1 | |
| 1219927 | 26 WASHER (44.4X57.6X5-MM THK) | 1 | |
| 1219928 | 27 SPRING | 1 | |
| 1219929 | 28 WASHER (40.4X61.4X5-MM THK) | 1 | |
| 8U5009 | 29 SHIM (0.1-MM THK) | 1 | |
| 8U5010 | 30 SHIM (0.3-MM THK) | 1 | |
| 1219930 | 31 SHIM (1-MM THK) | 1 | |
| 8T9598 | 32 RING-RETAINING | 1 | |
| 1219931 | 33 WASHER-SPECIAL | 1 | |
| 1835922 | 34 BEARING | 1 | |
| 1436159 | 35 SHIM (1-MM THK) | 1 | |
| 1436160 | SHIM (1.05-MM THK) | 1 | |
| 1436161 | SHIM (1.1-MM THK) | 1 | |
| 1436162 | SHIM (1.15-MM THK) | 1 | |
| 1436163 | SHIM (1.2-MM THK) | 1 | |
| 1436164 | SHIM (1.25-MM THK) | 1 | |
| 1436165 | SHIM (1.5-MM THK) | 1 | |
| 1436166 | SHIM (1.75-MM THK) | 1 | |
| 1219932 | 40 PLATE | 1 | |
| 1178210 | 41 DOWEL | 2 | |
| 1220963 | 42 FITTING GP-MOTOR | 1 | |
| 5P9757 | SEAL-O-RING | 1 | |
| 1481863 | 43 HOUSING | 1 | |
| 1219935 | 45 WASHER (3X7.5X1.5-MM THK) | 1 | |
| 1219936 | WASHER (3X7.5X1.6-MM THK) | 1 | |
| 1219937 | WASHER (3X7.5X1.7-MM THK) | 1 | |
| 1219938 | WASHER (3X7.5X1.8-MM THK) | 1 | |
| 1219939 | WASHER (3X7.5X1.9-MM THK) | 1 | |
| 1219940 | 50 WASHER (4X8X0.5-MM THK) | 1 | |
| 8C3131 | 51 SEAL-O-RING | 2 | |
| 1219941 | 52 RING | 2 | |
| 1219942 | 53 PIPE | 2 | |
| 1219943 | 54 RING | 2 | |
| 1219944 | 55 PISTON (150.8-MM) | 1 | |
| 1219945 | 56 PISTON (170.3-MM) | 1 | |
| 1219946 | 57 PIN | 2 | |
| 9T4901 | 58 NUT (M12X1-THD) | 2 | |
| 2683212 | 59 BOLT (M14X2X70-MM) | 9 | |
| 1766233 | 60 VALVE GP-RELIEF | 2 | |
| 1219948 | 61 VALVE GP-BRAKE CONTROL | 1 | |
| 1514764 | 62 REGULATOR GP-HOUSING | 1 | |
| 1069586 | SEAL-O-RING | 1 | |
| 1663718 | SEAL-O-RING | 1 | |
| 8U5942 | 63 SEAL-O-RING | 6 | |
| 6V5192 | 64 BOLT-SOCKET HEAD (M8X1.25X30-MM) | 4 | |
| 8U2088 | 65 ADAPTER GP | 1 | |
| 1H1023 | SEAL-O-RING | 1 | |
| 1060699 | 66 PLUG | 1 | |
| 8T7878 | 67 SEAL-O-RING | 1 | |
| 1436020 | 68 BOLT-SOCKET HEAD (M6X1X75-MM) | 2 | |
| 9T6322 | 72 PLUG AS | 1 | |
| 1178804 | SEAL-O-RING | 2 | |
| 1314678 | 73 NOZZLE | 2 | |
| 1691560 | 74 BOLT | 2 | |
| 1279651 | KIT-SEAL (TRAVEL MOTOR) | 1 |
