System And Components
138-8421 PUMP GP-ENGINE OILS/N 7BJ1-UP
Group No: 138-8421
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0254 | 1 BOLT (M8X1.25X30-MM) | 3 | |
| 6I0255 | 2 GEAR AS (20-TEETH) | 1 | |
| 0676927 | 3 BUSHING-TERMINAL | 1 | |
| 6I0256 | 4 WASHER | 1 | |
| 6I0257 | 5 PIPE | 1 | |
| 6I0258 | 6 SEAL | 4 | |
| 6I0259 | 7 FLANGE | 1 | |
| 6I0260 | 8 BOLT (M8X1.25X25-MM) | 2 | |
| 6I0650 | 9 BOLT (M10X1.5X65-MM) | 1 | |
| 6I0912 | 10 PUMP AS-ENGINE OIL | 1 | |
| 8N7998 | 11 DOWEL | 2 | |
| 0676928 | 12 CLIP | 1 | |
| 1004461 | 13 BOLT (M10X1.50X50-MM) | 1 | |
| 1068908 | 14 HOUSING | 1 | |
| 1068909 | 15 PIPE | 1 | |
| 1068911 | 16 HOUSING AS | 1 | |
| 6I0786 | 17 SPRING | 1 | |
| 6I0787 | 18 RING-RETAINING | 1 | |
| 7W4648 | 19 SEAT-SPRING | 1 | |
| 7W4782 | 20 PLUNGER | 1 | |
| 1013415 | 21 BOLT | 3 | |
| 1273294 | 22 SHAFT | 1 |
