System And Components
Assembly
100%

207-8366 STICK GPS/N TGH1-UP

Group No: 207-8366
Part NumberPart NameQty
20661031 BOOM1
13182032 SCREW-FLAT HEAD2
17014393 PIN2
17031154 PIN1
17031165 PLATE2
17031176 SHIM2
17031187 PLATE2
17014718 BEARING6
17014759 SHIM2
170147410 COVER6
170311911 BRACKET AS2
7X796012 BOLT (M12X1.75X220MM)2
170147913 RETAINER4
170094814 BOLT2
206610416 COVER1
170313017 PLATE2
170314118 CHAIN2
6V768819 LOCKNUT2
6V768720 LOCKNUT8
6V774321 LOCKNUT (M6X1 THD)6
6V979822 BOLT (M6X1.0X80MM)6
6V521523 BOLT (M8X1.25X16MM)10
9R570824 LOCKWASHER10
170138526 NUT (M55 THD)2
6V631728 BOLT (M10X1.5X20MM)2
170317729 WASHER4
113069330 LOCKWASHER2
6V918931 LOCKNUT4
206611032 BOOM1
170318233 CONSOLE1
170315534 PLATE2
170318535 PLATE1
170149236 BEARING7
170318637 SHIM1
170318738 SHIM1
170149339 SHIM7
170318841 YOKE1
170318942 PIN AS2
170319043 PIN1
170319144 PIN-COTTER2
6V819745 BOLT (M12X1.75X40MM)4
170149546 PIN1
170149647 WASHER1
8T506548 LOCKNUT1
206610949 BOOM1
170314350 PIN1
170314451 PIN2
170314552 PLATE2
170314653 PLATE1
6V820254 BOLT-HEX SOCKET (M8X1.25X16MM)1
170315656 BEARING1
170315758 SHIM2
170315859 SHIM1
170315960 SHIM1
170316061 SHIM1
170316262 PLATE1
170316363 PLATE1
170316465 ROLLER2
170316566 BUSHING2
170316667 SPACER1
170087268 FITTING5
8T699169 BOLT (M12X1.75X180MM)2
206611171 TUBE AS1
170316972 PLUG1
170317673 CONSOLE1
8T029374 BOLT (M12X1.75X20MM)4
