Assembly
100%

209-7168 DOOR GP-CABS/N TGH1-UP

Group No: 209-7168
Part NumberPart NameQty
6V76361 PIN AS-SPRING2
6W36282 CABLE1
8A85633 SPACER (8.6X20X10-MM THK)2
11075244 BUTTON10
12303805 SHIELD-STRIKER1
16655016 STRUT-NONLOCKING1
16655027 BALL JOINT2
17223838 LINK AS1
6V8185NUT (1/4-20-THD)1
1085471CLEVIS1
17722149 BALL2
180313910 LINKAGE AS1
180314511 LATCH AS-ROTARY1
187041312 STRIKER1
211918013 WINDOW1
211918514 PLATE AS1
6V9632NUT-WELD (M6X1-THD)2
211920115 DOOR AS1
1071161HINGE2
6V9632NUT-WELD (M6X1-THD)2
6V9632NUT-WELD (M6X1-THD)3
217004516 HANDLE1
217723417 NUT1
228040118 WASHER (8.2X16X6-MM THK)8
240003519 HANDLE AS1
186081520 BOLT (M6X1X20-MM)8
186081721 WASHER-HARD (7X19X2-MM THK)16
5P411622 WASHER-HARD (8.8X20.5X2-MM THK)10
7X772923 WASHER (11X25X3-MM THK)2
8T413824 BOLT (M6X1X20-MM)11
8T417125 BOLT (M6X1X12-MM)2
8T420026 BOLT (M8X1.25X16-MM)10
8T490827 BOLT (M8X1.25X25-MM)2
9X825628 WASHER (6.6X12X2-MM THK)11
128703729 SEAL (470-CM)NULL
