178-0509 STICK GPS/N KBN1-UP

Group No: 178-0509
Part NumberPart NameQty
17921991 STICK AS1
17009492 NUT (M65 THD)1
17013853 NUT (M55 THD)1
17014384 PIN1
17014395 PIN1
17014406 PIN1
17014427 PLATE2
17014438 SHIM2
17014449 PLATE2
170147110 BEARING4
170147411 COVER4
170147512 SHIM2
7X255113 BOLT (M12X1.75X200MM)2
170147714 BUSHING4
170147815 WASHER2
170147916 RETAINER4
170148017 BUSHING1
170148218 BUSHING1
170094819 BOLT2
170087220 FITTING2
170148621 COVER1
8T419922 BOLT (M8X1.25X12MM)4
8T422423 WASHER-HARD (8.8X16X2MM THK)4
8T697424 BOLT (M6X1X80MM)4
6V774325 LOCKNUT (M6X1 THD)4
6V768726 LOCKNUT (M12X1.75 THD)2
170149527 PIN1
170149628 WASHER1
8T506529 LOCKNUT1
6V519230 BOLT-SOCKET HEAD (M8X1.25X30MM)2
6V918931 LOCKNUT (M8X1.25 THD)2
194698132 STICK AS1
170148933 PLATE2
170149134 SHIM1
170149235 BEARING4
170149336 SHIM4
194698437 PIN1
