System And Components
179-6472 DOOR GP-CAB -LHS/N FDH1-UP; FDW1-UP
Group No: 179-6472 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E6647 | 1 SEAL (405-CM) | ||
| 7K1181 | 2 STRAP-CABLE | 4 | |
| 1083188 | 3 GROMMET | 2 | |
| 1091390 | 4 BOLT (M6X1X25-MM) | 4 | |
| 1258175 | 5 BLADE AS-WIPER (450-MM)(DOOR, LH) | 1 | |
| 1388454 | 6 SCREW-TRUSS HEAD (M4X0.7X10-MM) | 4 | |
| 1552263 | 7 WEDGE-PLUG LOCK (6-PIN) | 1 | |
| 1722383 | 8 LINK AS | 1 | |
| 6V8185 | 8A NUT (1/4-20-THD) | 1 | |
| 1085471 | 8B CLEVIS | 1 | |
| 1775280 | 9 HARNESS AS-WINDOW WIPER (LH) | 1 | |
| 1441636 | PIN-CONNECTOR (14-GA TO 18-GA) | 5 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 5 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(13-CM) | ||
| 1794810 | 10 MOTOR GP-WINDOW WIPER (DOOR, LH) | 1 | |
| 1803129 | 11 STRIKER | 1 | |
| 1803137 | 12 ARM AS-WIPER | 1 | |
| 3059190 | 12A NOZZLE AS-WASHER | 1 | |
| 1803146 | 13 LATCH AS (ROTARY) | 1 | |
| 1901188 | 14 PLATE | 1 | |
| 2007836 | 15 HANDLE AS (PULL) | 1 | |
| 2134762 | 16 DOOR AS (LH) | 1 | |
| 2134768 | 17 COVER | 1 | |
| 2134770 | 18 WINDOW | 1 | |
| 2134772 | 19 LINKAGE AS | 1 | |
| 1552274 | 20 KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 1782593 | 21 BUMPER | 2 | |
| 5C7261 | 22 NUT (M8X1.25-THD) | 6 | |
| 5P4116 | 23 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 6V7636 | 24 PIN AS-SPRING | 2 | |
| 7X7729 | 25 WASHER (11X25X3-MM THK) | 7 | |
| 8T4136 | 26 BOLT (M10X1.5X25-MM) | 7 | |
| 8T4138 | 27 BOLT (M6X1X20-MM) | 5 | |
| 8T4171 | 28 BOLT (M6X1X12-MM) | 2 | |
| 9X2038 | 29 WASHER (7X19X2-MM THK) | 2 | |
| 9X2044 | 30 SCREW-TRUSS HEAD (M6X1X16-MM) | 4 | |
| 9X8256 | 31 WASHER (6.6X12X2-MM THK) | 9 |
