144-9083 ACTUATOR GP-PUMP -HYDRAULIC PISTON PUMPS/N CEN1-UP

Group No: 144-9083
Part NumberPart NameQty
6V80021 SEAL-O-RING2
09509412 RING-RETAINING2
5A36043 BOLT-SOCKET HEAD (M8X1.25X25-MM)8
5P38634 SEAL-O-RING2
11909375 SPRING (OUTER)2
14490936 PISTON-STROKING1
14490947 ROD1
6V83988 SEAL-O-RING1
14490989 RETAINER2
6E442610 BUSHING2
6E441211 SPACER (8-MM THK)2
6E441412 SPACER (7.9-MM THK)2
6E441513 SPACER (7.95-MM THK)2
6E441614 SPACER (8.05-MM THK)2
6E441715 SPACER (8.1-MM THK)2
6E441316 SPACER (7.85-MM THK)2
119094217 NUT (M16X1.5-THD)1
144909518 COVER1
144909619 COVER1
6E442320 SPRING (INNER)2
144909721 RETAINER2
6E441822 RETAINER2
