Assembly
100%

155-7804 HOOD & GUARD GP -SEMI-UNIVERSAL BULLDOZER W/ SOUND SUPPRESSIONS/N S6S1-UP

Group No: 155-7804
Part NumberPart NameQty
6P22161 CAP (PUSH ON)60
6S62512 MOUNT2
6S66463 PIN-COTTER2
11146434 PLATE2
14508235 BUMPER4
15578036 CAM-LATCH2
15578197 HOOD AS1
8T3490NUT-WELD (M10X1.5-THD)2
1278732PIN-WELD6
15592838 DOOR AS (RH)1
1278732PIN-WELD10
15592859 SHEET AS (RH)1
1278732PIN-WELD1
155928610 SUPPORT AS (RH)1
9R2672BOSS-THREADED (M10X1.5X20-MM)1
8T3490NUT-WELD (M10X1.5-THD)2
155928811 DOOR AS (LH)1
1278732PIN-WELD10
155929012 SHEET AS (RH)1
1278732PIN-WELD11
155929113 SUPPORT AS (LH)1
8T3490NUT-WELD (M10X1.5-THD)1
155930114 PLATE AS (RH)1
8T3490NUT-WELD (M10X1.5-THD)2
155930215 PLATE AS (LH)1
8T3490NUT-WELD (M10X1.5-THD)2
174009916 LINER1
174010017 LINER1
174010118 LINER1
174010219 LINER1
174010320 LINER1
174010421 LINER1
174010522 LINER1
174010623 LINER (LH)1
174010724 LINER1
174010825 LINER1
174010926 LINER (LH)1
174011027 LINER1
177157028 LATCH AS4
2170733LOCK AS1
201403329 PLATE AS2
3H8726MOUNT AS1
201534930 SHAFT AS2
202735631 BRACKET AS (RH)1
202735732 BRACKET AS (LH)1
202735833 CAM (LATCH)2
222624634 SHEET AS (RH)1
1278732PIN-WELD6
222624735 SHEET AS (LH)1
1278732PIN-WELD6
224068736 BRACKET (LH)1
224068837 BRACKET (RH)1
6V851338 WASHER-HARD (11X35X2.5-MM THK)4
7X772939 WASHER (11X25X3-MM THK)8
7Y285440 SPACER (24X38X3-MM THK)4
8T412141 WASHER-HARD (11X21X2.5-MM THK)18
8T413742 BOLT (M10X1.5X20-MM)8
8T418543 BOLT (M10X1.5X50-MM)2
8T419544 BOLT (M10X1.5X30-MM)20
202529345 SEAL
