System And Components
256-0350 LINES GP-SAWS/N 1021-UP
Group No: 256-0350
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8P8701 | 1 WASHER-THRUST | 2 | |
| 8W6687 | 2 HOSE AS | 1 | |
| 1653144 | 3 HOSE AS | 1 | |
| 1756209 | 4 HOSE AS | 1 | |
| 1893158 | 5 SUPPRESSOR-ARC | 1 | |
| 1939230 | 6 VALVE GP-CHECK (SAW OIL SUPPLY) | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1992856 | 7 TUBE AS | 1 | |
| 2688259 | 8 PUMP GP-PISTON (SAW) | 1 | |
| 2218208 | 9 HOSE AS | 1 | |
| 2225781 | 10 VALVE GP-SOLENOID & MANIFOLD (DISC SAW) | 1 | |
| 2242335 | 11 PLATE | 1 | |
| 2252605 | 12 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 2255475 | 13 HOSE AS | 1 | |
| 2255476 | 14 HOSE AS | 1 | |
| 2255477 | 15 PLATE | 1 | |
| 2283649 | 16 SENSOR GP-PRESSURE (LOAD SENSING) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 2585058 | 17 HOSE AS | 1 | |
| 2586713 | 18 HOSE AS | 1 | |
| 0338248 | 19 CLIP (LOOP) | 1 | |
| 1195917 | 20 CLIP (LOOP) | 1 | |
| 1305300 | 21 CLIP | 3 | |
| 1488315 | 22 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488316 | 23 CONNECTOR AS | 2 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 1488327 | 24 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488339 | 25 CONNECTOR AS | 1 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488376 | 26 ELBOW AS | 1 | |
| 6V8983 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1488393 | 27 ELBOW AS | 1 | |
| 6V9852 | ELBOW (SWIVEL) | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488413 | 28 REDUCER AS | 2 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8934 | ADAPTER | 1 | |
| 1488455 | 29 UNION AS | 1 | |
| 6V8997 | UNION | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1504029 | 30 TEE AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V8780 | TEE | 1 | |
| 1536237 | 31 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1536248 | 32 ADAPTER AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T6663 | ADAPTER-PORT | 1 | |
| 1646861 | 33 UNION AS | 1 | |
| 6V8733 | UNION | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1716725 | 34 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 8T6451 | ELBOW | 1 | |
| 1P4582 | 35 FLANGE-HALF | 2 | |
| 1S0994 | 36 CLIP (LOOP) | 1 | |
| 2P1293 | 37 LOCKNUT (1-3/16-12-THD) | 2 | |
| 3J1907 | 38 SEAL-O-RING | 1 | |
| 4J0527 | 39 SEAL-O-RING | 1 | |
| 6V0852 | 40 CAP-DUST | 1 | |
| 7D1553 | 41 CLIP | 2 | |
| 8T4121 | 42 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4133 | 43 NUT (M10X1.5-THD) | 1 | |
| 8T4137 | 44 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4139 | 45 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4184 | 46 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4196 | 47 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4223 | 48 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8T5041 | 49 BOLT (M12X1.75X120-MM) | 4 |
