System And Components
217-9697 VALVE & MTG GP-MAIN CONTROL -7-BANKS/N 103206-UP
Group No: 217-9697
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P6412 | 1 HOSE (12-CM) | ||
| 8I3633 | 2 ADAPTER AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1626816 | SEAL | 1 | |
| 8T4983 | 3 CLAMP-HOSE | 2 | |
| 1544156 | 5 HOSE AS | 1 | |
| 2154722 | 7 HOSE AS | 1 | |
| 2220529 | 8 HOSE AS | 1 | |
| 2228731 | 9 VALVE AS-CHECK | 1 | |
| 6V8400 | SEAL-O-RING | 2 | |
| 2263628 | 10 HOSE AS | 1 | |
| 2283649 | 11 SENSOR GP-PRESSURE (LOAD SENSING) | 1 | |
| 2318781 | 12 TUBE AS | 1 | |
| 2318782 | 13 TUBE AS | 1 | |
| 2560500 | 14 VALVE GP-MAIN CONTROL (7-BANK) | 1 | |
| 2721488 | 15 HOSE AS | 1 | |
| 1488336 | 17 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488339 | 18 CONNECTOR AS | 1 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488356 | 19 ELBOW AS | 1 | |
| 6V9009 | ELBOW | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 1488367 | 20 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488392 | 21 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9853 | ELBOW | 1 | |
| 1503036 | 23 ELBOW AS | 1 | |
| 8T1905 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1536248 | 24 ADAPTER AS | 1 | |
| 8T6663 | ADAPTER-PORT | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1536252 | 25 CONNECTOR AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9X8408 | CONNECTOR | 1 | |
| 1553502 | 26 ADAPTER AS | 1 | |
| 3E7403 | ADAPTER | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1706541 | 27 ELBOW | 1 | |
| 1716723 | 28 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8T8899 | ELBOW | 1 | |
| 1731437 | 29 FLANGE-HALF | 2 | |
| 1P4578 | 30 FLANGE-HALF | 2 | |
| 1S0994 | 31 CLIP (LOOP) | 1 | |
| 2S4078 | 32 SEAL-O-RING | 1 | |
| 4J0522 | 33 SEAL-O-RING | 2 | |
| 5P2369 | 34 CLIP (LOOP) | 1 | |
| 6V9829 | 35 CAP (ORFS) | 1 | |
| 8T4121 | 36 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4137 | 37 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4183 | 38 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4196 | 39 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4223 | 40 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 2416185 | 41 PLUG AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5P9436 | PLUG | 1 |
