System And Components
217-9697 VALVE & MTG GP-MAIN CONTROL -7-BANKS/N 1041-193
Group No: 217-9697
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4566 | 1 HOSE | 1 | |
| 1460115 | 2 HOSE AS | 1 | |
| 1544156 | 3 HOSE AS | 1 | |
| 2033840 | 4 HOSE AS | 1 | |
| 2166122 | 5 HOSE AS | 1 | |
| 2188379 | 6 VALVE GP-MAIN CONTROL (7-BANK) | 1 | |
| 2218209 | 7 HOSE AS | 1 | |
| 2220529 | 8 HOSE AS | 1 | |
| 2228731 | 9 VALVE AS-CHECK | 1 | |
| 2283649 | 10 SENSOR GP-PRESSURE (LOAD SENSING) | 1 | |
| 3E3377 | WEDGE-RECEPTACLE LOCK (4-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 2318781 | 11 TUBE AS | 1 | |
| 2318782 | 12 TUBE AS | 1 | |
| 1488309 | 13 ADAPTER AS | 1 | |
| 2P8421 | ADAPTER-O-RING | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1488336 | 14 CONNECTOR AS | 3 | |
| 6V8636 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488356 | 15 ELBOW AS | 1 | |
| 6V9009 | ELBOW | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 1488360 | 16 ELBOW AS | 1 | |
| 6V9182 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488435 | 17 TEE AS | 1 | |
| 6V8781 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 1503036 | 18 ELBOW AS | 1 | |
| 8T1905 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1536248 | 19 ADAPTER AS | 1 | |
| 8T6663 | ADAPTER-PORT | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1706541 | 20 ELBOW | 1 | |
| 1731437 | 21 FLANGE-HALF | 2 | |
| 1P4578 | 22 FLANGE-HALF | 2 | |
| 1S0994 | 23 CLIP (LOOP) | 1 | |
| 2S4078 | 24 SEAL-O-RING | 1 | |
| 4J0522 | 25 SEAL-O-RING | 2 | |
| 5P2369 | 26 CLIP (LOOP) | 1 | |
| 8T4121 | 27 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4137 | 28 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4183 | 29 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4196 | 30 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4223 | 31 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4983 | 32 CLAMP-HOSE | 2 |
