System And Components
217-9698 VALVE & MTG GP-MAIN CONTROL -5-BANK, HARVESTER HEADS/N 1041-UP
Group No: 217-9698
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4566 | 1 HOSE | 1 | |
| 1137145 | 2 HOSE AS | 1 | |
| 1460115 | 3 HOSE AS | 1 | |
| 1487029 | 4 HOSE AS | 1 | |
| 1544156 | 5 HOSE AS | 1 | |
| 8I3633 | 6 ADAPTER AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1626816 | SEAL | 1 | |
| 1649422 | 7 HOSE AS | 1 | |
| 2188378 | 8 VALVE GP-MAIN CONTROL (HARVESTER HEAD, 5-BANK) | 1 | |
| 2220529 | 9 HOSE AS | 1 | |
| 2225811 | 10 VALVE GP-SOLENOID & MANIFOLD (LOAD SENSING) | 1 | |
| 2226383 | 11 HOSE AS | 1 | |
| 2226386 | 12 MANIFOLD | 1 | |
| 2228731 | 13 VALVE AS-CHECK | 1 | |
| 6V8400 | SEAL-O-RING | 2 | |
| 1488339 | 14 CONNECTOR AS | 1 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 2229141 | 15 TUBE AS | 1 | |
| 2242335 | 16 PLATE | 1 | |
| 2263628 | 17 HOSE AS | 1 | |
| 2283649 | 18 SENSOR GP-PRESSURE (LOAD SENSING) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 2318780 | 19 TUBE AS | 1 | |
| 2318781 | 20 TUBE AS | 1 | |
| 1195917 | 21 CLIP (LOOP) | 1 | |
| 1488309 | 22 ADAPTER AS | 1 | |
| 2P8421 | ADAPTER-O-RING | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1488336 | 23 CONNECTOR AS | 5 | |
| 6V8636 | CONNECTOR | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1488356 | 24 ELBOW AS | 1 | |
| 6V9009 | ELBOW | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 1488392 | 25 ELBOW AS | 1 | |
| 6V9853 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488367 | 26 ELBOW AS | 2 | |
| 6V9850 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488378 | 27 ELBOW AS | 4 | |
| 6V8724 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1488435 | 28 TEE AS | 1 | |
| 6V8781 | TEE | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1488424 | 29 TEE AS | 1 | |
| 8T8902 | ADAPTER-TEE | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1536248 | 30 ADAPTER AS | 2 | |
| 8T6663 | ADAPTER-PORT | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1536252 | 31 CONNECTOR AS | 1 | |
| 9X8408 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1706541 | 32 ELBOW | 1 | |
| 1731437 | 33 FLANGE-HALF | 2 | |
| 1P4578 | 34 FLANGE-HALF | 2 | |
| 1S0994 | 35 CLIP (LOOP) | 1 | |
| 2S4078 | 36 SEAL-O-RING | 1 | |
| 4J0522 | 37 SEAL-O-RING | 3 | |
| 5P2369 | 38 CLIP (LOOP) | 1 | |
| 7D1553 | 39 CLIP | 1 | |
| 8T4121 | 40 WASHER-HARD (11X21X2.5-MM THK) | 11 | |
| 8T4133 | 41 NUT (M10X1.5-THD) | 1 | |
| 8T4137 | 42 BOLT (M10X1.5X20-MM) | 7 | |
| 8T4177 | 43 BOLT (M8X1.25X90-MM) | 2 | |
| 8T4178 | 44 BOLT (M10X1.5X90-MM) | 4 | |
| 8T4183 | 45 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4223 | 46 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4224 | 47 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4983 | 48 CLAMP-HOSE | 2 | |
| 1726597 | 49 HOSE AS | 1 | |
| 1644180 | 50 PLUG AS | 1 | |
| 9S4181 | PLUG (1-5/16-12-THD) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1553502 | 51 ADAPTER AS | 1 | |
| 3E7403 | ADAPTER | 1 | |
| 6V8398 | SEAL-O-RING | 1 |
