System And Components
209-5234 METERING GP-ENGINE OIL -FRONT ENGINES/N JSM1-UP
Group No: 209-5234
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1R0750 | 1 FILTER-FUEL (ADVANCED EFFICIENCY)(OIL METERING) | 1 | |
| 1417156 | 2 BASE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 1427363 | 3 VALVE & MTG GP-OIL METERING | 1 | |
| 2177049 | 4 HOSE AS | 1 | |
| 0307946 | 5 ELBOW | 2 | |
| 0336042 | 6 SEAL-O-RING | 2 | |
| 0L1352 | 7 BOLT (3/8-16X3.25-IN) | 3 | |
| 0S1594 | 8 BOLT (3/8-16X1-IN) | 4 | |
| 1213954 | 9 HOSE AS | 1 | |
| 1682397 | 10 HOSE AS | 1 | |
| 3J1907 | 11 SEAL-O-RING | 1 | |
| 3J7354 | 12 SEAL-O-RING | 3 | |
| 3K0360 | 13 SEAL-O-RING | 2 | |
| 3K6060 | 14 LOCKNUT (3/8-16-THD) | 3 | |
| 4D9517 | 15 CLIP | 1 | |
| 4J5477 | 16 SEAL-O-RING | 2 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 5P9299 | 18 CLIP (LOOP) | 5 | |
| 5P9617 | 19 ADAPTER | 2 | |
| 6V8397 | 20 SEAL-O-RING | 2 | |
| 6V8555 | 21 NUT-FACE SEAL (1-14-THD) | 1 | |
| 6V8634 | 22 CONNECTOR | 1 | |
| 6V8636 | 23 CONNECTOR | 1 | |
| 6V8647 | 24 CONNECTOR | 1 | |
| 6V8937 | 25 REDUCER | 1 | |
| 7J9108 | 26 SEAL-O-RING | 1 | |
| 8C7307 | 27 ADAPTER | 1 | |
| 9S4185 | 28 PLUG (3/4-16-THD) | 2 | |
| 7W6333 | 29 SPACER (10.5X20X10.7-MM THK) | 1 | |
| 0S1588 | 30 BOLT (3/8-16X1.25-IN) | 1 | |
| 5M2894 | 31 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5P9299 | 32 CLIP (LOOP) | 2 | |
| 9F8885 | 33 SPACER (13.5X24X22.2-MM THK) | 1 | |
| 0S1587 | 34 BOLT (1/2-13X1.75-IN) | 1 | |
| 1240174 | 35 CLIP (LOOP) | 2 | |
| 5K3294 | 36 CLIP | 1 | |
| 5P8245 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 1 |
