System And Components
240-3321 PUMP GP-PISTON -HOOK-REARS/N CMX1-UP
Group No: 240-3321
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3811102 | 1 VALVE GP-PUMP CONTROL (PRESSURE, FLOW COMPENSATOR)(HOOK) | 1 | |
| 1838403 | 2 PUMP GP-CHARGE (HOOK) | 1 | |
| 2543383 | 3 HEAD GP-PUMP | 1 | |
| 2543382 | 4 ACTUATOR GP-PUMP | 1 | |
| 2717555 | 5 ROTATING GP-PUMP | 1 | |
| 1838454 | 6 HOUSING | 1 | |
| 0966095 | 7 PLUG | 1 | |
| 1237582 | 8 PIN-THREADED | 1 | |
| 9T3929 | 9 PLUG AS | 2 | |
| 6E5479 | SEAL | 1 | |
| 9T3928 | 10 PLUG AS | 2 | |
| 1878001 | SEAL | 1 | |
| 9S8002 | 11 PLUG (7/16-20-THD) | 2 | |
| 3J1907 | 12 SEAL-O-RING | 4 | |
| 6E4350 | 13 PIN | 1 | |
| 6E4351 | 14 PIN | 2 | |
| 1190964 | 15 ORIFICE | 1 | |
| 0966100 | 16 SEAL-O-RING | 3 | |
| 6E4385 | 17 LOCKNUT (M12X1.5-THD) | 1 | |
| 6E4614 | 18 PIN | 2 | |
| 2549121 | 19 VALVE GP-BYPASS | 1 | |
| 9S8006 | 20 PLUG (7/8-14-THD) | 1 | |
| 7M8485 | 21 SEAL-O-RING | 1 | |
| 8C5193 | 22 SEAL-O-RING | 1 | |
| 2M9780 | 23 SEAL-O-RING | 1 | |
| 9S8004 | 24 PLUG (9/16-18-THD) | 4 | |
| 3J7354 | 25 SEAL-O-RING | 2 | |
| 9S9334 | 26 PLUG (1-5/16-12-THD) | 1 | |
| 1119101 | 27 ORIFICE | 2 | |
| 1G3176 | 28 SCREW-LOCK | 1 | |
| 1197845 | 29 SEAL-O-RING | 1 | |
| 8T0271 | 30 BOLT-SOCKET HEAD (M10X1.5X35-MM) | 4 | |
| 6V8200 | 31 BOLT-SOCKET HEAD (M12X1.75X35-MM) | 4 | |
| 0950705 | 32 BOLT-SOCKET HEAD (M16X2X100-MM) | 4 | |
| 2463455 | 33 PLUG | 1 |
