System And Components
310-5528 LINES GP-STEERING -TRACTORS/N DBW1-151
Group No: 310-5528
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5T2795 | 1 CLAMP | 4 | |
| 6V0852 | 2 CAP-DUST | 3 | |
| 8C3451 | 3 CAP-DUST (HYDRAULIC OIL) | 1 | |
| 8T4984 | 4 CLAMP-HOSE | 4 | |
| 9T6685 | 5 CYLINDER GP-SERVO STEERING | 1 | |
| 1767695 | 6 VALVE GP-CHECK | 1 | |
| 1783620 | 7 STRAP-DUAL CLAMP | 2 | |
| 2334770 | 8 FITTING AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1837264 | VALVE AS-FLUID SAMPLING | 1 | |
| 2681514 | 9 UNION AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8C8493 | UNION | 1 | |
| 2961242 | 10 HOSE | 1 | |
| 2964400 | 11 STRAP AS | 1 | |
| 3089433 | 12 VALVE GP-CHECK | 1 | |
| 3177990 | 13 HOSE AS | 1 | |
| 3177992 | 14 HOSE AS | 1 | |
| 3177994 | 15 HOSE AS | 1 | |
| 3177997 | 16 HOSE AS | 1 | |
| 3264945 | 17 TUBE AS | 1 | |
| 3273934 | 18 HOSE AS | 1 | |
| 3309774 | 19 UNION AS | 2 | |
| 6V8995 | UNION (STRAIGHT) | 1 | |
| 2287090 | SEAL-O-RING | 2 | |
| 3385236 | 20 PLATE AS | 1 | |
| 4I6602 | BOSS (M12X1.75X20-MM) | 3 | |
| 8T4935 | BOSS-WELD (M10X1.5X45-MM) | 1 | |
| 3413482 | 21 PLATE AS | 1 | |
| 7Y2522 | PLATE | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3453832 | 22 BRACKET AS | 1 | |
| 3453835 | 23 BRACKET AS | 1 | |
| 3457777 | 24 PLATE AS | 1 | |
| 5G8480 | LUG (M10X1.5-THD) | 1 | |
| 3463821 | 25 BLOCK | 2 | |
| 3464999 | 27 HOSE AS | 1 | |
| 3465000 | 28 HOSE AS | 1 | |
| 3465002 | 29 TUBE AS | 1 | |
| 3466404 | 30 HOSE AS | 1 | |
| 3470128 | 31 HOSE AS | 1 | |
| 3470135 | 32 TUBE AS | 1 | |
| 3473129 | 33 HOSE AS | 1 | |
| 3473130 | 34 TUBE AS | 1 | |
| 3473131 | 35 TUBE AS | 1 | |
| 3477452 | 36 MANIFOLD | 1 | |
| 3497712 | 37 VALVE GP-STEERING | 1 | |
| 3524204 | 38 STRAP-CABLE | 6 | |
| 3587319 | 39 HOSE AS | 1 | |
| 3617148 | 40 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 6 | |
| 3623547 | 41 TUBE AS | 1 | |
| 3623548 | 42 TUBE AS | 1 | |
| 3623549 | 43 HOSE & TUBE AS | 1 | |
| 3662079 | 44 PLATE AS | 1 | |
| 7Y2522 | PLATE | 1 | |
| 3666001 | 45 TUBE AS | 1 | |
| 3666002 | 46 TUBE AS | 1 | |
| 3737067 | 47 TUBE AS | 1 | |
| 3737069 | 48 PLATE | 1 | |
| 3737070 | 49 HOSE AS | 1 | |
| 3737071 | 50 HOSE AS | 1 | |
| 3737072 | 51 HOSE AS | 1 | |
| 3737073 | 52 HOSE & TUBE AS | 1 | |
| 1650021 | HOSE (43-CM) | ||
| 6V9973 | COUPLING AS-PERMANENT | 1 | |
| 3737373 | 53 BRACKET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 9C7929 | BLOCK | 1 | |
| 9R2821 | BOSS (M10X1.5X15-MM) | 1 | |
| 1488340 | 54 CONNECTOR AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488346 | 55 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T1686 | ADAPTER-ELBOW | 1 | |
| 1488354 | 56 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 | |
| 1488357 | 57 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488364 | 58 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488411 | 59 PLUG AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1488444 | 60 TEE AS-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 1488457 | 61 UNION AS (STRAIGHT) | 2 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8995 | UNION (STRAIGHT) | 1 | |
| 1503028 | 62 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9343 | ELBOW | 1 | |
| 1503056 | 63 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 3 | |
| 6V8788 | TEE | 1 | |
| 1536246 | 64 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 3 | |
| 7X0820 | TEE | 1 | |
| 1552026 | 65 UNION AS | 1 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 6V8998 | UNION | 1 | |
| 1614336 | 66 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1240195 | ELBOW | 1 | |
| 1645567 | 67 COUPLER AS-QUICK DISCONNECT (MALE) | 3 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1645586 | 68 TEE AS | 2 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 7X0871 | TEE | 1 | |
| 1654931 | 69 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8077 | ELBOW | 1 | |
| 1984777 | 70 WASHER-HARD (11X25X10-MM THK) | 2 | |
| 1984778 | 71 WASHER-HARD (13.5X30X12-MM THK) | 15 | |
| 1P3704 | 72 SEAL-RECTANGULAR | 1 | |
| 1P3705 | 73 SEAL-RECTANGULAR | 1 | |
| 1P3706 | 74 SEAL-RECTANGULAR | 1 | |
| 1P4579 | 75 FLANGE-HALF | 4 | |
| 1P4582 | 76 FLANGE-HALF | 4 | |
| 2464996 | 77 WASHER-HARD (13.5X25.5X5-MM THK) | 4 | |
| 2H3926 | 78 LOCKWASHER | 4 | |
| 2P1293 | 79 LOCKNUT (1-3/16-12-THD) | 3 | |
| 2Y3812 | 80 CLIP | 1 | |
| 3196217 | 81 CONNECTOR AS | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196225 | 82 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196233 | 83 TEE AS | 1 | |
| 6V8782 | TEE | 1 | |
| 2287090 | SEAL-O-RING | 2 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3218636 | 84 UNION AS | 1 | |
| 8C8493 | UNION | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 3232263 | 85 SPACER (11.1X15.9X54.5-MM THK) | 2 | |
| 3524200 | 86 STRAP-CABLE | 6 | |
| 3E4321 | 87 CLIP (LOOP) | 2 | |
| 3G8047 | 88 GROMMET | 1 | |
| 3G8054 | 89 CLIP (TAB) | 1 | |
| 3G8057 | 90 CLIP (SLOT) | 1 | |
| 4D7735 | 91 CLIP | 2 | |
| 4J0520 | 92 SEAL-O-RING | 2 | |
| 4J0522 | 93 SEAL-O-RING | 1 | |
| 4J0524 | 94 SEAL-O-RING | 2 | |
| 4J0527 | 95 SEAL-O-RING | 2 | |
| 4J5267 | 96 SEAL-O-RING | 2 | |
| 5K1094 | 97 LOCKWASHER | 4 | |
| 5P1076 | 98 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 5P4107 | 99 LOCKWASHER | 1 | |
| 5P9297 | 100 CLIP (LOOP) | 3 | |
| 6D4244 | 101 CLIP (LOOP) | 2 | |
| 6D4246 | 102 CLIP (LOOP) | 2 | |
| 6V1889 | 103 CLIP (LOOP) | 1 | |
| 6V8367 | 104 LOCKWASHER | 2 | |
| 6V8397 | 105 SEAL-O-RING | 1 | |
| 6V9168 | 106 NUT (11/16-16-THD) | 1 | |
| 6V9169 | 107 NUT (13/16-16-THD) | 4 | |
| 6V9172 | 108 NUT (1-7/16-12-THD) | 1 | |
| 7G3832 | 109 GROMMET | 1 | |
| 7G3833 | 110 CLIP (TAB) | 1 | |
| 7G3834 | 111 CLIP (SLOT) | 1 | |
| 7X2551 | 112 BOLT (M12X1.75X200-MM) | 3 | |
| 7X7729 | 113 WASHER (11X25X3-MM THK) | 2 | |
| 8K2665 | 114 CLAMP-HALF | 4 | |
| 8M2773 | 115 CLIP (LOOP) | 1 | |
| 8T4121 | 116 WASHER-HARD (11X21X2.5-MM THK) | 27 | |
| 8T4133 | 117 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 118 BOLT (M10X1.5X25-MM) | 13 | |
| 8T4137 | 119 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4139 | 120 BOLT (M12X1.75X30-MM) | 6 | |
| 8T4172 | 121 BOLT (M10X1.5X80-MM) | 2 | |
| 8T4178 | 122 BOLT (M10X1.5X90-MM) | 2 | |
| 8T4183 | 123 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4184 | 124 BOLT (M12X1.75X45-MM) | 20 | |
| 8T4192 | 125 BOLT (M12X1.75X25-MM) | 8 | |
| 8T4195 | 126 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 127 WASHER-HARD (13.5X25.5X3-MM THK) | 34 | |
| 8T4244 | 128 NUT (M12X1.75-THD) | 1 | |
| 8T4648 | 129 BOLT (M12X1.75X70-MM) | 4 | |
| 8T4910 | 130 BOLT (M12X1.75X60-MM) | 4 | |
| 8T4956 | 131 BOLT (M12X1.75X35-MM) | 1 | |
| 8T6466 | 132 BOLT (M10X1.5X60-MM) | 8 |
