System And Components
373-4414 LADDER GPS/N NGX1-262
Group No: 373-4414
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 3L0594 | 2 SPACER (8.7X15.9X15.9-MM THK) | 4 | |
| 6V8993 | 3 UNION | 1 | |
| 1121817 | 4 VALVE-BALL | 1 | |
| 2042281 | 5 STRAP-CABLE | 4 | |
| 2241277 | 6 FILM-WARNING (LADDER-STAY CLEAR) | 1 | |
| 2441542 | 7 PLUG-ORIFICE | 1 | |
| 2544151 | 8 ROLLER | 2 | |
| 2544152 | 9 CYLINDER | 1 | |
| 2544171 | 10 PIN | 1 | |
| 2544187 | 11 PIN | 2 | |
| 2544189 | 12 BLOCK | 1 | |
| 2544190 | 13 PLATE | 1 | |
| 2545257 | 14 ELBOW | 1 | |
| 2545258 | 15 BREATHER | 1 | |
| 2594506 | 16 FILM-WARNING (CRUSH HAZARD) | 1 | |
| 2877843 | 17 PLATE AS | 1 | |
| 3152036 | 18 CABLE AS | 1 | |
| 3152037 | 19 HOOK | 1 | |
| 3152038 | 20 BLOCK | 2 | |
| 3160393 | 21 BEARING | 2 | |
| 3740520 | 22 BRACKET AS | 1 | |
| 3740524 | 23 STEP GP | 1 | |
| 3740586 | 24 SPRING-GAS | 1 | |
| 3740588 | 25 PLATE | 1 | |
| 3740589 | 26 COVER AS | 1 | |
| 3743192 | 27 PLATE | 1 | |
| 3743193 | 28 ARM AS | 1 | |
| 3743199 | 29 FLAP | 1 | |
| 3743273 | 30 LADDER AS | 1 | |
| 3760349 | 31 FILM-WARNING (LADDER-STAY CLEAR, READ OMM) | 1 | |
| 3814633 | 32 PLATE | 2 | |
| 3854424 | 33 PLATE AS | 1 | |
| 3854425 | 34 PLATE AS | 1 | |
| 3854426 | 35 PLATE AS | 1 | |
| 3857975 | 36 HOSE AS | 1 | |
| 3857976 | 37 HOSE AS | 1 | |
| 3872121 | 38 STRIP | 1 | |
| 3872122 | 39 STRIP | 1 | |
| 0950917 | 40 RING-RETAINING | 1 | |
| 1437685 | 41 ADAPTER-SPECIAL | 1 | |
| 1488433 | 42 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 1504050 | 43 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 8T0788 | ELBOW | 1 | |
| 1791732 | 44 BOLT (M6X1X16-MM) | 1 | |
| 1837121 | 45 BOLT (M10X1.5X35-MM) | 2 | |
| 1860815 | 46 BOLT (M6X1X20-MM) | 2 | |
| 1966723 | 47 BOLT (M10X1.5X70-MM) | 4 | |
| 2006345 | 48 SADDLE-MOUNTING (DUAL SWIVEL) | 2 | |
| 2P1279 | 49 LOCKNUT (9/16-18-THD) | 1 | |
| 3441202 | 50 BOLT (M8X1.25X12-MM) | 1 | |
| 3441203 | 51 BOLT (M8X1.25X16-MM) | 2 | |
| 3445675 | 52 NUT (M10X1.5-THD) | 4 | |
| 3685080 | 53 BOLT (M10X1.5X30-MM) | 10 | |
| 3685090 | 54 WASHER-HARD (11X25X3-MM THK) | 20 | |
| 3708026 | 55 WASHER-HARD (8.8X20.5X2-MM THK) | 8 | |
| 3J1907 | 56 SEAL-O-RING | 1 | |
| 4J5477 | 57 SEAL-O-RING | 1 | |
| 5L4035 | 58 RING-RETAINING (EXTERNAL) | 2 | |
| 6D3479 | 59 CLIP (LOOP) | 2 | |
| 6V8397 | 60 SEAL-O-RING | 2 | |
| 7X7729 | 61 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 62 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4137 | 63 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4191 | 64 BOLT (M10X1.5X16-MM) | 1 | |
| 9X2038 | 66 WASHER (7X19X2-MM THK) | 3 | |
| 7I1024 | 67 GUARD-HOSE (34-CM) | ||
| 7I1024 | 67A GUARD-HOSE (42-CM) |
