450-1522 PANEL GP-CIRCUIT BREAKERS/N KB41-424

Group No: 450-1522

Part Number	Part Name	Qty
3830772	1 PLATE AS	1
1712212	2 CIRCUIT BREAKER AS (105-AMPERE)(MAIN)	1
2164970	3 CIRCUIT BREAKER AS (120-AMPERE)(ALTERNATOR)	1
1H3244	LOCKWASHER	2
4E5724	WASHER (7X12X1-MM THK)	2
8T0122	NUT-FULL (1/4-28-THD)	2
2313930	4 RELAY AS (24-VOLT)(BLOWER FAN SPEED)	1
2418368	5 SWITCH GP-MAGNETIC (24-VOLT)(GLOW PLUG RELAY)	1
2431353	6 SPACER (11X20X35-MM THK)	1
3687944	7 COVER	1
3811040	8 STRIP	1
3849919	9 STRIP	1
4501519	10 CABLE AS	1
6V9023	TUBE-HEAT SHRINK (12.7-MM DIA)	3
8C3056	CABLE (2-GA, RED)(136-CM)
1352543	BOOT (RED)	1
4501520	11 CABLE AS	1
6T5598	TERMINAL-RING (1-GA TO 2-GA, 5/16-IN SCREW)	1
8C3056	CABLE (2-GA, RED)(184-CM)
1352543	BOOT (RED)	2
4501521	12 HARNESS AS-PANEL	1
1566451	13 SCREW-PAN HEAD (8-32X1-IN)	6
1684511	14 SCREW-PAN HEAD (10-32X1-IN)	4
2640168	15 STUD-TAPERLOCK (M10X1.5X50-MM)	2
3537957	16 GROMMET	7
4B2043	17 NUT (8-32-THD)	2
5C2890	18 NUT (M6X1-THD)	3
5H6565	19 CIRCUIT BREAKER AS (30-AMPERE)(ENGINE ECM)	1
6V8376	SCREW-MACHINE (8-32X0.25-IN)	2
9B7233	LOCKWASHER	2
6D4246	20 CLIP (LOOP)	7
6V7357	21 BOLT (M6X1X25-MM)	3
7K1181	22 STRAP-CABLE	1
8D7265	23 CIRCUIT BREAKER AS (40-AMPERE)(GLOW PLUG)	1
6V8376	SCREW-MACHINE (8-32X0.25-IN)	2
9B7233	LOCKWASHER	2
8T4121	24 WASHER-HARD (11X21X2.5-MM THK)	5
8T4133	25 NUT (M10X1.5-THD)	2
8T4137	26 BOLT (M10X1.5X20-MM)	1
8T4138	27 BOLT (M6X1X20-MM)	4
8T4183	28 BOLT (M12X1.75X40-MM)	2
8T4185	29 BOLT (M10X1.5X50-MM)	1
8T4223	30 WASHER-HARD (13.5X25.5X3-MM THK)	2
9G9882	31 CIRCUIT BREAKER AS (10-AMPERE)(HYDRAULIC FILL PUMP)	1
6V8376	SCREW-MACHINE (8-32X0.25-IN)	2
9B7233	LOCKWASHER	2
9X8256	32 WASHER (6.6X12X2-MM THK)	10
