System And Components
546-5529 PLANETARY GP-TRANSMISSIONS/N TS31-UP
Group No: 546-5529
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3K1432 | 1 RING-METAL SEAL | 2 | |
| 3P7019 | 2 SEAL-METAL | 2 | |
| 3T9960 | 3 DISC-FRICTION | 5 | |
| 4S5824 | 4 RETAINER | 1 | |
| 6P2233 | 5 GEAR-PLANETARY (20-TEETH) | 3 | |
| 6P7742 | 6 SHAFT-PLANETARY | 4 | |
| 6P7743 | 7 SHAFT-PLANETARY | 4 | |
| 6P7968 | 8 PLATE-CLUTCH | 4 | |
| 6P7983 | 9 RING-RETAINING | 1 | |
| 6P7985 | 10 RING-SEAL | 2 | |
| 6P8003 | 11 GEAR (27-TEETH) | 4 | |
| 6P8005 | 12 GEAR (23-TEETH) | 8 | |
| 6Y5352 | 13 DISC-FRICTION | 19 | |
| 6Y5952 | 14 GEAR AS-SUN (42-TEETH) | 1 | |
| 6Y2109 | CARRIER-SEAL | 1 | |
| 6Y7880 | 15 SHAFT-PLANETARY | 4 | |
| 6Y8030 | 16 RING-SEAL | 1 | |
| 6Y9713 | 17 GEAR AS-SUN (44-TEETH) | 1 | |
| 8S0527 | PLUG-CUP | 2 | |
| 7G0437 | 18 PLATE-CLUTCH | 20 | |
| 1M8649 | 19 RING-RETAINING | 1 | |
| 7G5444 | 20 CARRIER-PLANETARY | 1 | |
| 7G5569 | 21 GEAR-RING (83-TEETH) | 1 | |
| 7G5572 | 22 GEAR-SUN (29-TEETH) | 1 | |
| 7G5593 | 23 GEAR-SUN (38-TEETH) | 1 | |
| 7G5594 | 24 GEAR-SUN (38-TEETH) | 1 | |
| 7G5614 | 25 SHAFT-PLANETARY | 3 | |
| 7G6061 | 26 COUPLING | 1 | |
| 7G6062 | 27 GEAR-RING (82-TEETH) | 1 | |
| 7G8121 | 28 RING-LOCK | 2 | |
| 7T1285 | 29 GEAR-PLANETARY (23-TEETH) | 4 | |
| 9H5546 | 30 DOWEL | 6 | |
| 8D2714 | 31 SEAL-O-RING | 4 | |
| 8E1666 | 32 PLATE-RETAINER | 1 | |
| 8E8297 | 33 DISC-THRUST | 6 | |
| 8E8299 | 34 DISC-THRUST | 32 | |
| 9H5604 | 35 RING-RETAINING | 1 | |
| 8P8950 | 37 RING-METAL SEAL | 2 | |
| 8P9723 | 38 RING-SEAL | 1 | |
| 9G1234 | 39 SPRING-DISC | 5 | |
| 9G1491 | 40 CARRIER-PLANETARY | 1 | |
| 9M1503 | 41 RING-METAL SEAL | 1 | |
| 9N4460 | 42 HOUSING AS-CLUTCH | 1 | |
| 3S8109 | PIN-SPRING | 1 | |
| 4S8537 | DOWEL | 1 | |
| 9P5558 | 43 RING-RETAINING | 1 | |
| 9W0517 | 44 CARRIER-PLANETARY | 1 | |
| 9W0518 | 45 CARRIER-RING | 1 | |
| 9W0519 | 46 DISC-THRUST | 1 | |
| 3990266 | 47 HOUSING | 1 | |
| 1127847 | 48 HOUSING | 1 | |
| 1769273 | 49 PISTON | 1 | |
| 1862517 | 50 GEAR-RING (82-TEETH) | 1 | |
| 2133719 | 51 PLATE-REACTION | 1 | |
| 2375747 | 52 HOUSING-CLUTCH | 1 | |
| 2378246 | 53 BOLT-SPECIAL | 12 | |
| 2379060 | 54 GEAR (51-TEETH) | 1 | |
| 5483277 | 55 SHAFT | 1 | |
| 2379067 | 56 CARRIER-PLANETARY | 1 | |
| 3453771 | 57 PLATE | 1 | |
| 2379070 | 58 HOUSING AS | 1 | |
| 1A2223 | DOWEL | 1 | |
| 1150532 | PLUG-ORIFICE | 1 | |
| 2940877 | 59 BOLT-SPECIAL | 3 | |
| 3624283 | 60 GEAR-RING (86-TEETH) | 1 | |
| 3668298 | 61 PISTON | 5 | |
| 0353360 | 62 RING-RETAINING | 1 | |
| 0616711 | 63 RING-RETAINING | 2 | |
| 1434642 | 64 BEARING-SPECIAL | 1 | |
| 1M3150 | 65 DOWEL-REACTION | 6 | |
| 1M3151 | 66 DOWEL-REACTION | 6 | |
| 3532622 | 67 SHAFT AS-OUTPUT | 1 | |
| 8S3426 | DOWEL | 1 | |
| 9G7683 | BUSHING | 2 | |
| 7G3711 | 68 GEAR-RING (82-TEETH) | 1 | |
| 2352496 | 69 WASHER-HARD (15.5X26X3-MM THK) | 3 | |
| 2429522 | 70 RACE-SPECIAL ROLLER BEARING | 1 | |
| 2429523 | 71 PLATE-END | 1 | |
| 2500839 | 72 BEARING AS-ROLLER | 1 | |
| 3453770 | 73 HOUSING-SUPPORT | 1 | |
| 3634541 | 74 SPRING | 8 | |
| 3792185 | 75 BALL BEARING | 2 | |
| 3P3441 | 76 RING-RETAINING | 1 | |
| 3S8109 | 77 PIN-SPRING | 15 | |
| 3T7584 | 78 SPRING | 4 | |
| 4H4737 | 79 PIN-SPRING | 4 | |
| 5L2931 | 80 RING-RETAINING | 1 | |
| 5P3131 | 81 BEARING AS-ROLLER | 3 | |
| 5P3930 | 82 BEARING AS-ROLLER | 8 | |
| 5P8245 | 83 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 6P7772 | 84 RING-SEAL | 1 | |
| 6P7773 | 85 RING-SEAL | 5 | |
| 6V0834 | 86 RING-RETAINING | 1 | |
| 6V0835 | 87 RING-RETAINING | 1 | |
| 6V1586 | 88 RING-RETAINING | 1 | |
| 6V5696 | 89 BOLT (M12X1.75X80-MM) | 1 | |
| 7G3710 | 90 ROD | 4 | |
| 7G5675 | 91 RING-SEAL | 5 | |
| 7G5730 | 92 RING-SEAL | 1 | |
| 7S4534 | 93 BEARING-CAGED | 8 | |
| 7X7608 | 94 RING-RETAINING | 1 | |
| 8T0106 | 95 BOLT (M12X1.75X100-MM) | 1 | |
| 9G5828 | 96 SPRING | 4 |
