System And Components
8E-2376 LIGHTING GP-FLOODS/N 4NK1-UP
Group No: 8E-2376
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1068964 | 1 LAMP GP-FLOOD (24-VOLT) | 2 | |
| 8E1931 | 2 GUARD | 2 | |
| 1141052 | 3 BRACKET AS | 4 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 5M3062 | 4 BOLT (3/8-16X0.75-IN) | 5 | |
| 5P1075 | 5 WASHER-HARD (10.2X22.5X3-MM THK) | 5 | |
| 8E2137 | 6 WIRE AS | 2 | |
| 6V8188 | 7 NUT (1/2-13-THD) | 2 | |
| 8T8917 | 8 BOLT (1/2-13X1.25-IN) | 8 | |
| 5P1076 | 9 WASHER-HARD (13.5X30X4-MM THK) | 10 | |
| 8T8912 | 10 BOLT (5/16-18X2.25-IN) | 4 | |
| 8T4224 | 11 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 6V8189 | 12 NUT (5/16-18-THD) | 4 | |
| 1076689 | 13 LAMP GP-FLOOD (24-VOLT) | 2 | |
| 8E2152 | 14 BRACKET AS | 2 | |
| 7T1099 | LINK | 1 | |
| 8Y0176 | 15 WIRE AS (LH) | 1 | |
| 3W5360 | 16 WIRE AS (RH) | 1 | |
| 3S2093 | 17 STRAP-CABLE | 2 | |
| 5P2228 | 18 BOLT (1/2-13X1-IN) | 2 | |
| 3T3048 | 19 CLIP AS | 1 | |
| 8M2772 | 20 CLIP (LOOP) | 1 | |
| 3W1563 | 21 COVER | 1 | |
| 5P5754 | 22 SEAL (.6M) | 1 | |
| 6V8518 | 23 FILM-INSTRUCTION | 1 | |
| 8Y0643 | 24 BOX AS | 1 | |
| 9V7451 | NUT-WELD (1/4-20-THD) | ||
| 8G5390 | 25 WIRE AS | 1 | |
| 5S7349 | 26 BOLT (1/4-20X0.5-IN) | 5 | |
| 8T4205 | 27 WASHER-HARD (7.2X14.5X2-MM THK) | 9 | |
| 5L2579 | 28 GROMMET | 1 | |
| 8L8413 | 29 STRAP-CABLE (WHITE) | 1 | |
| 3K8782 | 30 FUSE (10-AMPERE) | 1 | |
| 4K5122 | 31 HOLDER AS-FUSE | 1 | |
| 7N2867 | CAP-FUSE HOLDER | 1 | |
| 8D2676 | 32 SWITCH AS-TOGGLE (SINGLE POLE)(FLOOD LIGHTS) | 1 | |
| 3L8187 | LOCKWASHER | 2 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 2 | |
| 7X0618 | 33 WASHER-HARD (13.5X40X5-MM THK) | 2 | |
| 8T8919 | 34 BOLT (1/2-13X1.75-IN) | 2 | |
| 7X0266 | 35 BOLT (1/4-20X3-IN) | 1 | |
| 6V8185 | 36 NUT (1/4-20-THD) | 1 |
