System And Components
8G-4391 CONTROL GP-CLUTCHS/N 4NK1-UP
Group No: 8G-4391
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3D7423 | 1 PIPE | 1 | |
| 6V8183 | 2 NUT-FULL (3/8-24-THD) | 8 | |
| 4D4064 | 3 ROD END (3/8-24-THD)(BEARING) | 7 | |
| 8T7008 | 4 BOLT (3/8-16X3-IN) | 1 | |
| 2K4973 | 5 LOCKNUT (3/8-16-THD) | 5 | |
| 3D6923 | 6 ROD-CONTROL | 1 | |
| 3W9214 | 7 PEDAL | 1 | |
| 8G6033 | 8 SHAFT | 1 | |
| 1B8706 | 9 KEY-WOODRUFF | 3 | |
| 5S7382 | 10 BOLT (3/8-16X1.375-IN) | 6 | |
| 8G6028 | 11 LEVER | 1 | |
| 8T1173 | 12 SEAL-LIP TYPE | 6 | |
| 8T1177 | 13 BEARING-ROLLER | 6 | |
| 9G4937 | 14 LEVER | 1 | |
| 5M3062 | 15 BOLT (3/8-16X0.75-IN) | 1 | |
| 9L8781 | 16 WASHER (0.406X1.5X0.188-IN THK) | 1 | |
| 1B0676 | 17 PIN | 1 | |
| 3B4617 | 18 PIN-COTTER | 1 | |
| 4H4737 | 19 PIN-SPRING | 1 | |
| 8G6032 | 20 SHAFT | 1 | |
| 5P8167 | 21 BOLT (3/8-16X0.625-IN) | 1 | |
| 3K0925 | 22 WASHER (10.3X25.4X3-MM THK) | 1 | |
| 4L9337 | 23 BOLT (3/8-16X1.5-IN) | 2 | |
| 4L6454 | 24 BOLT (3/8-16X1-IN) | 3 | |
| 5P1075 | 25 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 3W2452 | 26 LEVER | 1 | |
| 6V8801 | 27 NUT (3/8-16-THD) | 2 | |
| 8T4994 | 28 WASHER-HARD (20X36.5X3.5-MM THK) | 1 | |
| 3W2451 | 29 LEVER | 1 | |
| 3W4474 | 30 LEVER | 1 | |
| 5K7638 | 31 ROD-CONTROL | 1 | |
| 1A9252 | 32 END-ADJUSTMENT ROD | 1 | |
| 8E4796 | 33 ROD | 1 | |
| 8G6029 | 34 PIVOT AS | 1 | |
| 7X0594 | 35 WASHER-HARD (20X38X3-MM THK) | 2 |
