System And Components
192-8579 LINES GP-AIR CONDITIONERS/N CKG1-UP
Group No: 192-8579
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P6356 | 1 PLATE | 1 | |
| 2W9719 | 2 CORE AS-CONDENSER | 1 | |
| 3E4092 | 3 FITTING AS-AIR CONDITIONER | 1 | |
| 5D1026 | 4 CLAMP-HOSE | 13 | |
| 1036100 | 5 FITTING AS-AIR CONDITIONER (QUICK DISCONNECT) | 2 | |
| 1065532 | 6 RECEIVER-DRYER GP | 1 | |
| 1145333 | 7 SWITCH AS-PRESSURE | 1 | |
| 1630872 | 8 COMPRESSOR GP-REFRIGERANT | 1 | |
| 1658051 | 9 TUBE | 1 | |
| 1688861 | 10 VALVE AS (HEAT/COLD MIXING) | 1 | |
| 1691414 | 11 PIPE | 1 | |
| 1711948 | 12 PIPE | 1 | |
| 1714475 | 13 CARRIER AS | 1 | |
| 1928610 | 14 HOSE AS | 1 | |
| 1985097 | 15 CARRIER AS | 1 | |
| 2100732 | 16 HOSE AS | 1 | |
| 2100770 | 17 HOSE AS | 1 | |
| 2100771 | 18 HOSE AS | 1 | |
| 3E4075 | 19 FITTING | 2 | |
| 1894523 | 21 BOSS | 1 | |
| 1S1015 | 22 CLIP | 1 | |
| 2P4556 | 23 CLIP | 2 | |
| 3D2824 | 24 SEAL-O-RING | 1 | |
| 3E6812 | 25 FITTING AS-AIR CONDITIONER | 1 | |
| 3E4051 | CAP-SEAL (AIR CONDITIONER) | 1 | |
| 3E4057 | VALVE AS | 1 | |
| 8T4133 | 26 NUT (M10X1.5 THD) | 11 | |
| 6V1889 | 27 CLIP | 1 | |
| 7X2538 | 28 BOLT (M8X1.25X100-MM) | 4 | |
| 8T4121 | 29 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 1163715 | 30 STUD-TAPERLOCK (M10X1.5X85-MM) | 1 | |
| 8T4200 | 31 BOLT (M8X1.25X16-MM) | 1 | |
| 8T4224 | 32 WASHER-HARD (8.8X16X2-MM THK) | 10 | |
| 8T6466 | 33 BOLT (M10X1.5X60-MM) | 1 | |
| 8T6870 | 34 BOLT (M8X1.25X70-MM) | 4 | |
| 8T7529 | 35 CLIP | 4 | |
| 8T7547 | 36 BOLT (M8X1.25X30-MM) | 1 | |
| 0672551 | 37 CLIP | 2 | |
| 9X7378 | 38 SEAL-O-RING | 1 | |
| 9X7380 | 39 SEAL-O-RING | 4 | |
| 9X7381 | 40 SEAL-O-RING | 2 | |
| 9X7382 | 41 SEAL-O-RING | 2 | |
| 5P0767 | 42 HOSE (73CM) | NULL | |
| 5P0765 | 43 HOSE (946CM) | NULL | |
| 5P7070 | 44 INSULATION-STRIP (.06M EA) | 2 | |
| 8T4137 | 45 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4136 | 46 BOLT (M10X1.5X25-MM) | 2 | |
| 8M2773 | 47 CLIP | 3 |
