System And Components
210-0768 AIR COMPRESSOR GPS/N CLT207-UP
Group No: 210-0768
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2S3440 | 1 CLAMP-HOSE | 2 | |
| 5F5434 | 2 VALVE AS-RELIEF (AIR VENT) | 1 | |
| 6I1240 | 3 GOVERNOR AS-AIR COMPRESSOR | 1 | |
| 2S2923 | COVER | 1 | |
| 9M0402 | KIT-GOVERNOR OVERHAUL (AIR COMPRESSOR) | 1 | |
| 6V0405 | 4 SEAL-BONDED | 1 | |
| 7C5478 | 5 SUPPORT-COMPRESSOR | 1 | |
| 1606071 | 6 HOSE AS | 1 | |
| 8T7491 | 7 CONNECTOR | 2 | |
| 9X6772 | 8 STRAP-CABLE | 1 | |
| 0393593 | 9 HOSE AS | 1 | |
| 1450840 | 10 AIR COMPRESSOR GP | 1 | |
| 1561233 | 11 FITTING | 1 | |
| 1606012 | 12 HOSE AS | 1 | |
| 1606058 | 13 HOSE AS | 1 | |
| 1606059 | 14 HOSE AS | 1 | |
| 1611303 | 15 BRACKET | 1 | |
| 1614757 | 16 BRACKET | 1 | |
| 1625870 | 17 VALVE | 1 | |
| 1625871 | 18 VALVE | 1 | |
| 1625872 | 19 TANK | 1 | |
| 1625873 | 20 SPRING | 1 | |
| 1625874 | 21 RING | 1 | |
| 1626008 | 22 STRAP | 1 | |
| 1626094 | 23 CLAMP | 2 | |
| 1626125 | 24 ADAPTER | 1 | |
| 1626130 | 25 ADAPTER | 1 | |
| 1626131 | 26 ADAPTER | 1 | |
| 1661212 | 27 U-BOLT | 2 | |
| 1666318 | 28 FITTING | 1 | |
| 1722404 | 29 FILM-INSTRUCTION (AIR TANK WATER DRAIN) | 1 | |
| 1746802 | 30 SEAL | 4 | |
| 2200949 | 31 HOSE AS | 1 | |
| 1S0994 | 32 CLIP | 1 | |
| 2M9780 | 33 SEAL-O-RING | 1 | |
| 3D2824 | 34 SEAL-O-RING | 1 | |
| 2T1922 | 35 ELBOW | 1 | |
| 3K0360 | 36 SEAL-O-RING | 2 | |
| 4J5477 | 37 SEAL-O-RING | 3 | |
| 4S1962 | 38 CLIP | 1 | |
| 5C7261 | 39 NUT (M8X1.25-THD) | 4 | |
| 5P4116 | 40 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 6D4246 | 41 CLIP | 2 | |
| 6V1722 | 42 ADAPTER-O-RING | 1 | |
| 6V8398 | 43 SEAL-O-RING | 9 | |
| 9X6582 | 44 NUT (13/16-16-THD) | 2 | |
| 6V8625 | 45 ELBOW | 1 | |
| 6V8642 | 46 CONNECTOR | 1 | |
| 6V8935 | 47 REDUCER-O-RING | 2 | |
| 6V8639 | 48 CONNECTOR | 1 | |
| 6V9844 | 49 TEE-SWIVEL | 1 | |
| 7C3179 | 50 GEAR (50-TEETH) | 1 | |
| 7J9108 | 51 SEAL-O-RING | 1 | |
| 7X0274 | 52 BOLT (5/16-18X2.75-IN) | 2 | |
| 7X0492 | 53 ELBOW | 1 | |
| 7X2619 | 54 BOLT (M6X1.0X20-MM) | 1 | |
| 8C6872 | 55 CONNECTOR | 2 | |
| 8T4121 | 56 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4136 | 57 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4189 | 58 BOLT (M8X1.25X20-MM) | 1 | |
| 8T4200 | 59 BOLT (M8X1.25X16-MM) | 1 | |
| 8T4223 | 60 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4224 | 61 WASHER-HARD (8.8X16X2-MM THK) | 7 | |
| 9L5125 | 62 ELBOW | 1 | |
| 9X8256 | 63 WASHER (6.6X12X2-MM THK) | 1 | |
| 1625781 | 64 CABLE (1.0M) | NULL | |
| 5P0767 | 65 HOSE (235CM) | NULL | |
| 8T4908 | 66 BOLT (M8X1.25X25-MM) | 1 | |
| 6B6682 | 67 NUT-FULL (3/4-16-THD) | 1 |
