System And Components
198-0027 COVER GP-CYLINDER BLOCKS/N BMA1652-UP
Group No: 198-0027
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W6544 | 1 COVER | 1 | |
| 3E2332 | 2 ELBOW | 1 | |
| 4P5918 | 3 CLIP | 3 | |
| 4Y9652 | 4 GASKET | 3 | |
| 7W3871 | 5 COVER-SIDE | 3 | |
| 7W3872 | 6 SLEEVE | 6 | |
| 8C3445 | 7 CAP-DUST | 1 | |
| 9X2097 | 8 STUDBOLT (M8X1.25 THD) | 1 | |
| 9Y0747 | 9 MANIFOLD-OIL | 1 | |
| 1107618 | 10 BOLT AS | 4 | |
| 1837264 | 11 VALVE AS-FLUID SAMPLING | 1 | |
| 3J1907 | 12 SEAL-O-RING | 3 | |
| 4F9653 | 13 SEAL-O-RING | 1 | |
| 5C7261 | 14 NUT (M8X1.25 THD) | 1 | |
| 6V2317 | 15 BOLT (M8X1.25X30MM) | 12 | |
| 6V5217 | 16 BOLT (M8X1.25X20MM) | 11 | |
| 6V5839 | 17 WASHER (11X21X2.5MM THK) | 2 | |
| 6V5842 | 18 BOLT (M10X1.50X40MM) | 2 | |
| 9M1974 | 19 WASHER-HARD (8.8X16X2MM THK) | 22 | |
| 9S4191 | 20 PLUG (9/16-18 THD) | 1 | |
| 1U8846 | 21 SEALANT-GASKET | NULL |
