System And Components
198-0028 PULLEY GP-IDLERS/N BMA1-UP
Group No: 198-0028
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 FITTING-GREASE | 1 | |
| 6I9235 | 2 BEARING AS-ROLLER | 1 | |
| 1004026 | 3 RETAINER-BEARING | 1 | |
| 1117238 | 4 PLATE | 1 | |
| 1253723 | 5 PULLEY-FAN | 1 | |
| 1230856 | 6 SHAFT-FAN | 1 | |
| 1345690 | 7 BRACKET-FAN BEARING | 1 | |
| 1441102 | 8 BELT TIGHTENER | 1 | |
| 1980029 | 9 BRACKET AS | 1 | |
| 5M6509 | 10 SEAL-O-RING | 1 | |
| 6V3822 | 11 BOLT (M10X1.5X35MM) | 4 | |
| 6V3940 | 12 BOLT (M8X1.25X25MM) | 3 | |
| 6V5217 | 13 BOLT (M8X1.25X20MM) | 10 | |
| 6V5219 | 14 BOLT (M8X1.25X40MM) | 2 | |
| 6V5839 | 15 WASHER (11X21X2.5MM THK) | 5 | |
| 8T0643 | 16 BOLT (M10X1.50X80MM) | 1 | |
| 9M1974 | 17 WASHER-HARD (8.8X16X2MM THK) | 7 |
