System And Components
311-7280 LINES GP-POWER TRAIN OILS/N Z9K357-452
Group No: 311-7280
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1F1609 | 1 SPACER (13.5X25.4X39.7-MM THK) | 3 | |
| 1N4296 | 2 PROTECTION GP-VANDALISM (OIL FILLER CAP) | 1 | |
| 4E6888 | 3 HOSE AS | 1 | |
| 4H6112 | 4 BREATHER (AUGER DRIVE GEAR) | 2 | |
| 4K1209 | 5 HOSE | 1 | |
| 6C3997 | 6 SPACER (15X20X10-MM THK) | 1 | |
| 6G0584 | 7 ELBOW | 1 | |
| 6I8563 | 8 VALVE GP-TORQUE CONV PRIORITY | 1 | |
| 7S1801 | 9 ANCHOR-CHAIN | 1 | |
| 8C3447 | 10 CAP-DUST | 2 | |
| 8E9727 | 11 VALVE GP-RELIEF (TORQUE CONVERTER OUTLET PRESS) | 1 | |
| 8P9859 | 12 ELBOW | 1 | |
| 8R0752 | 13 ADAPTER | 2 | |
| 8T4985 | 14 CLAMP-HOSE | 4 | |
| 8T6703 | 15 CLAMP-HOSE | 8 | |
| 8X4886 | 16 ELBOW | 1 | |
| 1248909 | 17 ELBOW | 2 | |
| 1597630 | 18 JUNCTION BLOCK | 2 | |
| 1658764 | 19 BRACKET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 1668556 | 20 HOSE AS | 1 | |
| 1803377 | 21 FILTER GP-OIL (POWER TRAIN) | 1 | |
| 1809595 | 22 BRACKET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 1942148 | 23 HOSE AS | 1 | |
| 1973295 | 24 FLANGE-HALF | 6 | |
| 2352482 | 25 SEAL-RECTANGULAR | 1 | |
| 2432746 | 26 HOSE | 2 | |
| 2530896 | 27 TUBE AS | 1 | |
| 2542474 | 28 HOSE AS | 1 | |
| 2780250 | 29 GAUGE GP-SIGHT (POWER TRAIN OIL) | 1 | |
| 2796750 | 30 PUMP GP-TRANSMISSION | 1 | |
| 2800000 | 31 HOSE AS | 1 | |
| 2800001 | 32 HOSE AS | 1 | |
| 2800002 | 33 ADAPTER | 1 | |
| 3056885 | 34 HOSE AS | 1 | |
| 3056891 | 35 TUBE AS | 1 | |
| 3065390 | 36 TUBE AS | 1 | |
| 3065391 | 37 TUBE AS | 1 | |
| 3065394 | 38 BRACKET AS | 1 | |
| 9R1733 | BOSS (M10X1.5X66.5-MM) | 1 | |
| 9R4595 | BOSS (M12X1.75X30-MM) | 1 | |
| 3086365 | 39 BRACKET AS | 1 | |
| 7X0752 | BOSS-WELD (M10X1.5X65-MM) | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 8T3851 | BOSS-WELD (M10X1.5X17.5-MM) | 2 | |
| 3117287 | 40 HOSE AS | 1 | |
| 3117288 | 41 HOSE AS | 1 | |
| 3117289 | 42 HOSE AS | 1 | |
| 3117290 | 43 HOSE AS | 1 | |
| 3117291 | 44 TUBE | 1 | |
| 3117292 | 45 TUBE | 1 | |
| 3117295 | 46 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 9R1733 | BOSS (M10X1.5X66.5-MM) | 1 | |
| 3168703 | 47 HOSE AS | 1 | |
| 3168704 | 48 HOSE AS | 1 | |
| 3362917 | 49 TUBE AS | 1 | |
| 3362921 | 50 TUBE AS | 1 | |
| 3548323 | 51 TUBE AS | 1 | |
| 3548324 | 52 TUBE AS | 1 | |
| 1331295 | 53 FILTER GP-OIL (POWER TRAIN) | 1 | |
| 1488336 | 54 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488353 | 55 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488367 | 56 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488378 | 57 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488434 | 58 TEE AS | 1 | |
| 1P3705 | 59 SEAL-RECTANGULAR | 5 | |
| 1P4578 | 60 FLANGE-HALF | 2 | |
| 1P4579 | 61 FLANGE-HALF | 14 | |
| 1P4582 | 62 FLANGE-HALF | 14 | |
| 1S0994 | 63 CLIP (LOOP) | 3 | |
| 1V7753 | 64 SPACER (0.546X0.841X1.75-IN THK) | 1 | |
| 2808912 | 65 BOLT (M10X1.5X75-MM) | 2 | |
| 2H6338 | 66 SEAL-O-RING | 1 | |
| 2Y3812 | 67 CLIP | 1 | |
| 3J7354 | 68 SEAL-O-RING | 4 | |
| 4D7388 | 69 CLIP | 1 | |
| 4J0522 | 70 SEAL-O-RING | 6 | |
| 4J0524 | 71 SEAL-O-RING | 10 | |
| 4J0527 | 72 SEAL-O-RING | 8 | |
| 5P1076 | 73 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 5P2566 | 74 BOLT (1/2-13X1.5-IN) | 12 | |
| 5P7468 | 75 CLIP (SLOT) | 3 | |
| 5P7469 | 76 CLIP (TAB) | 3 | |
| 5P7470 | 77 CLIP (SLOT) | 5 | |
| 5P7471 | 78 CLIP (TAB) | 5 | |
| 5P7703 | 79 GROMMET (52-MM ID) | 4 | |
| 5P8182 | 80 GROMMET (46-MM ID) | 1 | |
| 5P8444 | 81 GROMMET (37-MM ID) | 3 | |
| 5P9297 | 82 CLIP (LOOP) | 1 | |
| 6B6205 | 83 SPACER (0.438X0.875X1.281-IN THK) | 1 | |
| 6H4006 | 84 GROMMET | 1 | |
| 6V1324 | 85 GROMMET | 1 | |
| 6V1867 | 86 CLIP (SLOT) | 2 | |
| 6V1868 | 87 CLIP (TAB) | 2 | |
| 6V1869 | 88 GROMMET (65-MM ID) | 2 | |
| 6V1889 | 89 CLIP (LOOP) | 1 | |
| 6V8397 | 90 SEAL-O-RING | 3 | |
| 6W6231 | 91 SPACER (0.493X0.675X1.78-IN THK) | 2 | |
| 7G3413 | 92 CLIP (SLOT) | 1 | |
| 7G3414 | 93 CLIP (TAB) | 1 | |
| 7S8920 | 94 CLIP (SLOT) | 10 | |
| 7S8921 | 95 CLIP (TAB) | 10 | |
| 7X2549 | 96 BOLT (M12X1.75X100-MM) | 4 | |
| 7X2550 | 97 BOLT (M12X1.75X110-MM) | 3 | |
| 7X2553 | 98 BOLT (M16X2X40-MM) | 6 | |
| 7X3392 | 99 WASHER-HARD (13.5X22.5X3-MM THK) | 20 | |
| 7X7729 | 100 WASHER (11X25X3-MM THK) | 2 | |
| 8C3446 | 101 VALVE-SAMPLING | 2 | |
| 8M4443 | 102 SEAL-O-RING | 1 | |
| 8M4986 | 103 SEAL-O-RING | 1 | |
| 8M5127 | 104 SEAL-O-RING | 1 | |
| 8M5254 | 105 SEAL-O-RING | 1 | |
| 8M8157 | 106 SEAL-O-RING | 1 | |
| 8R0721 | 107 SPACER (11X16X35-MM THK) | 1 | |
| 8S0948 | 108 CLIP | 1 | |
| 8T4121 | 109 WASHER-HARD (11X21X2.5-MM THK) | 27 | |
| 8T4122 | 110 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 8T4133 | 111 NUT (M10X1.5-THD) | 3 | |
| 8T4136 | 112 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4139 | 113 BOLT (M12X1.75X30-MM) | 11 | |
| 8T4140 | 114 BOLT (M16X2X60-MM) | 4 | |
| 8T4172 | 115 BOLT (M10X1.5X80-MM) | 2 | |
| 8T4176 | 116 BOLT (M12X1.75X90-MM) | 8 | |
| 8T4178 | 117 BOLT (M10X1.5X90-MM) | 4 | |
| 8T4183 | 118 BOLT (M12X1.75X40-MM) | 29 | |
| 8T4184 | 119 BOLT (M12X1.75X45-MM) | 17 | |
| 8T4185 | 120 BOLT (M10X1.5X50-MM) | 2 | |
| 8T4194 | 121 BOLT (M12X1.75X50-MM) | 2 | |
| 8T4196 | 122 BOLT (M10X1.5X35-MM) | 6 | |
| 8T4223 | 123 WASHER-HARD (13.5X25.5X3-MM THK) | 100 | |
| 8T4244 | 124 NUT (M12X1.75-THD) | 1 | |
| 8T4648 | 125 BOLT (M12X1.75X70-MM) | 4 | |
| 8T4910 | 126 BOLT (M12X1.75X60-MM) | 15 | |
| 8T4956 | 127 BOLT (M12X1.75X35-MM) | 7 | |
| 8T6466 | 128 BOLT (M10X1.5X60-MM) | 2 | |
| 8T6868 | 129 BOLT (M12X1.75X80-MM) | 5 | |
| 8T7338 | 130 BOLT (M16X2X45-MM) | 4 | |
| 8T8919 | 131 BOLT (1/2-13X1.75-IN) | 4 | |
| 8T9393 | 132 BOLT (5/8-11X1.5-IN) | 2 | |
| 9X8257 | 133 WASHER (17.5X30X3.5-MM THK) | 14 |
