System And Components
166-2582 CYLINDER GP-TILTS/N 1WP1-UP; 3RP1-UP
Group No: 166-2582
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1662583 | 1 CYLINDER AS | 1 | |
| 1662584 | CAP AS | 1 | |
| 2J8489 | BEARING | 1 | |
| 1J2921 | 2 BOLT (1-1/2-12X3.75-IN) | 1 | |
| 3S6162 | 3 WASHER-HARD (40.5X67X6-MM THK) | 1 | |
| 3J9703 | 4 RING-WEAR | 1 | |
| 5J4991 | 5 SEAL AS | 1 | |
| 7J8955 | 6 RING-BACKUP (RUBBER) | 1 | |
| 7J8956 | 7 SEAL-O-RING | 1 | |
| 8T8379 | 8 SEAL-HEAD | 1 | |
| 9T0094 | 9 RING-WEAR | 1 | |
| 8E5703 | 10 SHIM (0.8-MM THK) | 24 | |
| 8J2880 | 11 CAP AS-BEARING | 1 | |
| 7X0373 | 12 BOLT (3/4-10X5.5-IN) | 4 | |
| 6V8182 | 13 NUT (3/4-10-THD) | 4 | |
| 1D4709 | 14 BOLT (1-8X3-IN) | 4 | |
| 5P8250 | 15 WASHER (28X49X5-MM THK) | 4 | |
| 6E5527 | 16 HEAD | 1 | |
| 1U4069 | 17 ROD AS | 1 | |
| 3J6572 | SHIM (0.5-MM THK) | 14 | |
| 4T0259 | 18 PISTON | 1 | |
| 1672469 | 19 SEAL-WIPER | 1 | |
| 1672319 | 20 SEAL-U-CUP | 1 | |
| 1672208 | 21 SEAL AS-BUFFER | 1 | |
| 8T1408 | KIT-HYDRAULIC CYLINDER SEAL | 1 | |
| 1126550 | KIT-HYDRAULIC CYLINDER SEAL | 1 | |
| 1363752 | KIT-HYDRAULIC CYLINDER SEAL | 1 | |
| 1368645 | KIT-HYDRAULIC CYLINDER SEAL | 1 |
