System And Components
1W-3889 BELT TENSIONER GPS/N 8HB1-482
Group No: 1W-3889
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S0175 | 1 PIN-CLEVIS | 1 | |
| 3B4615 | 2 PIN-COTTER | 1 | |
| 2W2169 | 3 ARM AS (BELT TIGHTENER) | 1 | |
| 4S5367 | 3A BUSHING AS (MOUNT) | 1 | |
| 2S6196 | 3B SHAFT-PULLEY | 1 | |
| 4N0955 | 3C DOWEL (PIN) | 1 | |
| 2M2742 | 4 PLATE-RETAINER | 1 | |
| 0L1351 | 5 BOLT (3/8-16X0.875-IN) | 1 | |
| 5M2894 | 6 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 2S6151 | 7 GASKET | 1 | |
| 2S6150 | 8 COVER-PULLEY | 1 | |
| 2S6160 | 9 WASHER-HARD (10.2X32X5-MM THK) | 1 | |
| 4M6425 | 10 BOLT (5/16-18X1-IN) | 4 | |
| 4N2697 | 11 PULLEY-TIGHTENER | 1 | |
| 3B6552 | 12 ELBOW-PIPE | 1 | |
| 8B2327 | 13 RING-RETAINING | 1 | |
| 7N5959 | 14 SPRING | 1 | |
| 4N2690 | 15 SHAFT AS | 1 | |
| 4N0955 | 17 DOWEL | 1 | |
| 2W3376 | 18 SCREW | 1 | |
| 4L9337 | 19 BOLT (3/8-16X1.5-IN) | 4 | |
| 5M9735 | 20 SEAL-LIP TYPE | 1 | |
| 6B1124 | 21 BALL BEARING | 2 | |
| 1S8687 | 22 SPACER (25.5X33.4X31.75-MM THK) | 1 | |
| 9B7237 | 23 BOLT (3/8-16X1.25-IN) | 1 | |
| 5P9297 | 24 CLIP (LOOP) | 2 | |
| 9G0682 | 25 HOSE AS | 1 | |
| 3B8485 | 26 ELBOW | 1 | |
| 3B7896 | 27 ELBOW-STREET | 1 | |
| 3B9400 | 28 CONNECTOR | 1 | |
| 5S7379 | 29 BOLT (3/8-16X0.875-IN) | 1 | |
| 8T4896 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 |
