System And Components
147-4656 ADAPTER GP-FAST FILL FUELPART OF 147-4653 SCRAPER AR
Group No: 147-4656
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P2566 | 1 BOLT (1/2-13X1.5-IN) | 4 | |
| 8T4223 | 2 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 1P4582 | 3 FLANGE-HALF | 2 | |
| 4J0527 | 4 SEAL-O-RING | 2 | |
| 2J5608 | 5 COVER | 1 | |
| 8X1644 | 6 TUBE AS | 1 | |
| 1361968 | 7 BLOCK | 1 | |
| 1P3709 | 8 SEAL-RECTANGULAR | 1 | |
| 7X0336 | 9 BOLT (1/2-13X5.5-IN) | 4 | |
| 8X3473 | 10 PIPE | 1 | |
| 1361982 | 11 PIPE | 1 | |
| 3B6500 | 12 ELBOW | 2 | |
| 2175703 | 13 RECEIVER (FAST FILL FUEL) | 1 | |
| 9D0630 | 14 CAP-DUST (FAST FILL FUEL) | 1 | |
| 6V1867 | 15 CLIP (SLOT) | 2 | |
| 6V1868 | 16 CLIP (TAB) | 2 | |
| 8W9059 | 17 STRIP | 2 | |
| 8T8917 | 18 BOLT (1/2-13X1.25-IN) | 2 | |
| 8W5658 | 19 HOSE | 1 | |
| 6L4725 | 20 CLAMP-HOSE | 3 | |
| 4T1314 | 21 VENT AS-FUEL TANK | 1 | |
| 5T8592 | SEAL-BODY | 1 | |
| 5T8645 | KIT-VENT (FUEL TANK)(FAST FILL) | 1 | |
| 5P8502 | 22 PADLOCK GP (FAST FILL FUEL) | 1 | |
| 5P8500 | KEY | 1 | |
| 8Y6364 | SLEEVE | 1 | |
| 9M7958 | 23 CLAMP-HOSE | 1 | |
| 2050672 | 24 PLUG AS | 1 | |
| 9S7583 | PLUG | 1 | |
| 0304606 | SEAL-O-RING | 1 |
