System And Components
188-2505 DOOR GP-CABS/N 4MZ1-UP
Group No: 188-2505
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4E1384 | 1 BUMPER-CONICAL | 2 | |
| 7X2497 | 2 HANDLE-DOOR | 1 | |
| 8T4747 | 3 BRACKET | 2 | |
| 8Y4807 | 4 HANDLE AS | 1 | |
| 8Y4501 | SPRING-HANDLE | 1 | |
| 8Y6386 | 5 SEAL-HANDLE | 1 | |
| 9G2761 | 6 LATCH AS-DOOR | 1 | |
| 1076117 | 7 COVER (LH) | 1 | |
| 1619647 | 8 PLATE | 1 | |
| 1682457 | 9 LATCH AS-DOOR (HOLD OPEN) | 1 | |
| 1693995 | 10 SEAL | 1 | |
| 1882506 | 11 DOOR AS | 1 | |
| 8T3612 | 11A NUT-WELD (M8X1.25-THD) | 2 | |
| 1882520 | 11B HANDRAIL | 1 | |
| 1882529 | 11C HANDLE | 1 | |
| 1882596 | 12 GLASS | 1 | |
| 1937463 | 13 ROD | 1 | |
| 1937469 | 14 INSULATION | 1 | |
| 1937470 | 15 CLIP | 1 | |
| 1937481 | 16 COVER-END | 1 | |
| 5C7261 | 17 NUT (M8X1.25-THD) | 2 | |
| 8T4180 | 18 SCREW-MACHINE (M5X0.8X20-MM) | 4 | |
| 8T4181 | 19 BOLT (M6X1X20-MM) | 5 | |
| 8T4205 | 20 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8T4971 | 21 BOLT (M6X1X30-MM) | 4 | |
| 9X2042 | 22 SCREW-TRUSS HEAD (M6X1X12-MM) | 9 | |
| 1882534 | 23 SEAL |
